Description

The ABB NBUB-41C is a DC bus bar board (Bus Bar Board COA) specifically designed for the ABB ACS600 series frequency converters, serving as the critical main circuit DC bus physical connection carrier . This industrial-grade copper bus bar distributes the rectified DC bus power to inverter modules and braking unit interfaces, making it the backbone of energy transmission within the drive system.

Engineered with a tinned electrolytic copper bus bar, the ABB NBUB-41C features the COA suffix, which denotes “Configuration Option A”—the version equipped with a built-in braking chopper interface . This is a crucial differentiator from the simplified NBUB-41 variant without the terminal set. Designed for Class H insulation (≤180°C) and compliant with IEC 60947 standards, the board reliably handles the electrical and thermal demands of high-power industrial drives.

Application Scenarios

In a mining operation running a 630kW ball mill driven by an ACS600 drive, maintenance engineers noticed intermittent DC bus arcing during start-up—a telltale sign of contact resistance degradation on the aging bus bar board. Replacing the failing unit with the ABB NBUB-41C restored rock-solid DC bus connectivity between the rectifier and inverter IGBT modules. The COA suffix ensured compatibility with the existing NBRA braking chopper, avoiding the need for separate adapter bars. After installation, the drive resumed normal operation with stable DC bus voltage distribution across the entire power section. The ABB NBUB-41C now withstands the daily thermal cycling and high-current impacts of mill start-up, eliminating the arcing incidents and extending the service life of adjacent IGBT modules.

Parameters

Main Parameters	Value/Description
Product Model	NBUB-41C (Bus Bar Board COA)
Manufacturer	ABB
Product Category	DC Bus Bar / Bus Main Board
Material	Tinned electrolytic copper
DC Bus Voltage	320–1050 V DC (330–660 V DC typical for ACS600)
Insulation Class	Class H (≤180°C), meeting IEC 60947 clearance requirements
Compatible Series	ABB ACS600 R6/R7 frames (ACS601-0070 ~ ACS607)
Interface Ports	Power unit (IGBT), control unit (NAMC-11C/NPOW-41C), brake chopper (COA exclusive)
Operating Temperature	-10°C to +55°C (storage -40°C to +85°C)
Dimensions	Approx. 254 × 51 × 229 mm
Weight	Approx. 0.3–0.5 kg
Material Number	58937703

Technical Principles and Innovative Values

Innovation Point 1: Purpose-Built DC Power Distribution Architecture
The ABB NBUB-41C functions as the physical and electrical backbone of the ACS600 DC link. Positioned between the rectifier and inverter sections, the board is a thick, tinned copper bus bar that collects DC power from the rectifier modules and distributes it to the IGBT inverter modules and, via the COA-exclusive terminal, to the NBRA braking chopper . Its bolted, hard-mounted design ensures a high-current, low-impedance connection critical for stable drive operation.

Innovation Point 2: COA Brake Chopper Interface
The “COA” (Configuration Option A) suffix is the key distinguishing feature of the ABB NBUB-41C versus the standard NBUB-41. This variant includes dedicated interface terminals for connecting an NBRA series braking chopper . In applications with overhauling loads or high-inertia deceleration, this interface allows excess regenerative energy to be safely dissipated into a braking resistor, preventing DC bus overvoltage trips.

Innovation Point 3: High Thermal Class and Material Selection
Constructed from high-conductivity, tinned electrolytic copper, the ABB NBUB-41C meets Class H insulation standards (up to 180°C) and complies with IEC 60947 electrical clearance requirements . This thermal resilience is essential in harsh, high-dust environments like mines, where thermal cycling and shock loads continuously stress power components .
