Description

Product Overview

The ABB IMDS002 is a high-performance digital output(DO)module designed for seamless integration within ABB’s AC500 programmable logic controller(PLC)platform,particularly optimized for use in the AC500 eDCS(enhanced Distributed Control System)architecture.As a critical component in industrial automation systems,the ABB IMDS002 provides 16 relay-based digital outputs,enabling reliable switching of field devices such as contactors,solenoid valves,indicator lamps,and small motors.This module plays a vital role in command execution and process actuation,ensuring that control logic translates into precise physical actions across machinery and processes.The ABB IMDS002 is part of ABB’s modular I/O ecosystem,allowing scalable expansion of control cabinets to meet the evolving demands of complex automation applications.

Engineered for durability and long-term reliability,the ABB IMDS002 features electrically isolated output groups and galvanic isolation from the backplane bus,enhancing system protection against voltage spikes,ground loops,and electromagnetic interference.It is designed for 35 mm DIN rail mounting and integrates effortlessly with other AC500 series modules,including CPUs(e.g.,PM5xx),power supplies,analog modules,and communication interfaces.Whether deployed in discrete manufacturing,water treatment,energy management,or building automation,the ABB IMDS002 delivers consistent,high-speed switching performance under demanding industrial conditions.Its compatibility with ABB’s Automation Builder engineering suite further enhances configurability,diagnostics,and remote monitoring,reinforcing the AC500 platform’s reputation for robustness and future-proof scalability in mission-critical environments.

Technical Specifications

Product Model IMDS002

Manufacturer ABB

Product Type 16-Channel Digital Output Module

Series/Platform AC500 eDCS System

Output Type Relay(Form A)

Number of Outputs 16 outputs(2 groups of 8)

Maximum Switching Voltage 250 VAC/30 VDC

Maximum Switching Current 2 A per point

Electrical Isolation Group-to-group and bus isolation

Installation 35 mm DIN rail

LED Indicators 1 x OK(module status),output status LEDs

Operating Temperature 0°C to+55°C

Storage Temperature-25°C to+70°C

Relative Humidity 5%to 95%RH,non-condensing

Certifications CE,UL,CSA

Main Features and Advantages

The ABB IMDS002 stands out in industrial control applications due to its combination of reliability,flexibility,and intelligent design.A key advantage is its relay-based output configuration,which provides true galvanic isolation and the ability to switch both AC and DC loads.This makes the ABB IMDS002 ideal for applications requiring high inrush current handling,such as driving contactors or motor starters,where solid-state outputs may not be suitable.The module’s 16 outputs are divided into two isolated groups of eight,preventing fault propagation between subsystems and enhancing overall system safety and diagnostic clarity.

Another significant benefit is its seamless integration and expandability within the AC500 ecosystem.The ABB IMDS002 can be easily added to an existing rack to extend output capacity without requiring major system redesign.Its compact DIN rail footprint optimizes control cabinet space,making it ideal for both new installations and retrofit projects.Each output is equipped with individual status LEDs,enabling fast visual verification of signal activity during commissioning or troubleshooting.The module supports hot-swap capability in redundant configurations,minimizing downtime during maintenance.When used with ABB’s Automation Builder software,the ABB IMDS002 enables remote configuration,diagnostics,and firmware updates,significantly improving operational efficiency.The ABB IMDS002 also features robust electrical isolation between the field side and the backplane bus,protecting the CPU and communication modules from transients and noise.These features collectively make the ABB IMDS002 a trusted solution for engineers seeking a durable,high-performance digital output module for demanding industrial environments.

Application Field

The ABB IMDS002 is widely deployed across industries where reliable switching of high-power loads is essential for safe and efficient operations.In OEM machinery and factory automation,it is commonly used to control contactors,solenoid valves,and pilot lights on packaging lines,assembly machines,and material handling systems.Its ability to handle inductive loads makes it ideal for applications involving motor control and high-energy actuation.In water and wastewater treatment plants,the ABB IMDS002 activates pumps,agitators,and valve actuators,ensuring that treatment processes respond accurately to control logic and sensor feedback.

In energy and power generation,the module plays a role in auxiliary control systems,switching cooling fans,alarm horns,and breaker indicators.Its robust relay outputs are well-suited for environments with fluctuating loads and electrical noise.The ABB IMDS002 is also used in building management systems to control HVAC components,lighting circuits,and access control mechanisms.In process industries such as food and beverage or pharmaceuticals,it supports batch sequencing by activating mixers,conveyors,and filling valves.Because the ABB IMDS002 integrates natively with the AC500 eDCS platform,it is often selected for greenfield projects and system upgrades where long-term support,scalability,and interoperability are key requirements.Its proven reliability across diverse sectors makes the ABB IMDS002 a preferred choice for engineers designing robust,future-ready automation systems.

Related Products

ABB IMDS001–An 8-channel relay output module,ideal for smaller applications or when fewer outputs are needed,offering a more compact solution.

ABB IMDSI22–A 16-channel 24VDC digital input module,often used alongside the ABB IMDS002 to provide complete I/O coverage.

ABB IMDSI21–An 8-channel digital input module,suitable for pairing with the ABB IMDS002 in mixed I/O configurations.

ABB PM501–A compact CPU for the AC500 series,commonly paired with the ABB IMDS002 in small to mid-sized control systems.

ABB PS302–A 24VDC power supply module designed to power the AC500 rack,including the ABB IMDS002 and other I/O modules.

ABB CM571–A high-performance CPU with integrated Ethernet and fieldbus interfaces,used in advanced applications with the ABB IMDS002.

ABB Automation Builder–The engineering software suite used to configure,program,and diagnose systems using the ABB IMDS002 and other AC500 components.

ABB IMDSO32–A 32-channel transistor output module for high-density DC switching applications,offering an alternative for solid-state needs.

Installation and Maintenance

Pre-installation preparation:Before installing the ABB IMDS002,ensure that the control cabinet is clean,properly grounded,and equipped with a 35 mm DIN rail.Verify that the AC500 CPU and power supply modules are correctly installed and that the backplane bus is intact.Confirm the field wiring uses shielded cables for noise immunity and that all connected loads are within the module’s rated switching capacity(2 A per point,250 VAC/30 VDC).The ABB IMDS002 should be mounted adjacent to other AC500 modules,ensuring the bus connectors align properly and the module clicks securely into place.After installation,power up the system gradually and use Automation Builder to verify that the module is recognized and all outputs respond correctly during functional testing.

Maintenance recommendations:The ABB IMDS002 is a solid-state and relay hybrid module requiring minimal maintenance.Periodically inspect the DIN rail mounting and terminal screws for tightness,especially in environments with vibration.Clean dust buildup from the module and surrounding components to prevent overheating.Monitor the OK LED during routine checks;a steady green light indicates normal operation,while a flashing or off light may indicate a fault.In the event of a failure,use Automation Builder to diagnose output status and isolate faulty field devices.The ABB IMDS002 supports hot-swap replacement in redundant systems,minimizing downtime.Always follow proper ESD precautions when handling the module to prevent electrostatic damage.

Product Guarantee

We stand firmly behind every ABB IMDS002 module we supply,guaranteeing 100%genuine ABB products sourced through authorized channels.Each ABB IMDS002 undergoes rigorous inspection and functional testing before shipment to ensure it meets ABB’s stringent quality standards for performance and reliability.We offer a comprehensive warranty that covers defects in materials and workmanship,reflecting our confidence in the durability of the ABB IMDS002 under industrial operating conditions.Our technical support team is available to assist with integration,configuration,and troubleshooting,ensuring a smooth deployment process.Whether you are building a new control system or replacing a legacy module,choosing the ABB IMDS002 means investing in a proven,high-quality component backed by robust engineering and reliable after-sales support.We are committed to delivering not just a product,but a complete solution that enhances the stability and longevity of your automation infrastructure.
