Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | NINT-45C BSM25GD120DN2 |
| Manufacturer | ABB (with Infineon Silicon Technology) |
| Product Type | IGBT Power Module |
| Configuration | Three-Phase Full Bridge |
| Collector-Emitter Voltage | 1200V |
| Continuous Collector Current | 35A (DC) |
| Maximum Power Dissipation | 200W |
| Collector-Emitter Saturation Voltage | 3.0V (typical) |
| Gate-Emitter Voltage | ±20V |
| Input Capacitance | 1.65nF @ 25V |
| Rise Time | 130ns (typical) |
| Fall Time | 100ns (typical) |
| Package Type | EconoPACK 2 (17 pins) |
| Dimensions (L x W x H) | 107.5mm x 45mm x 17mm |
| Mounting Type | Panel / Through Hole |
| Operating Junction Temperature | -40°C to +125°C |
| Electrical Life | 100,000 cycles |
| Mechanical Life | 50,000 hours |
| Certifications | CE, UL, RoHS Compliant |
| Country of Origin | Germany |
Main Features and Advantages
Superior power density and efficiency: The NINT-45C BSM25GD120DN2 delivers exceptional power handling capability within a compact EconoPACK 2 footprint measuring only 107.5mm x 45mm x 17mm . With a 1200V blocking voltage and 35A continuous current rating, this module provides the power density required for demanding industrial applications while maintaining a low collector-emitter saturation voltage of 3.0V, minimizing conduction losses and improving overall system efficiency .
Fast switching performance: Engineered for high-frequency operation, the NINT-45C BSM25GD120DN2 features rapid rise and fall times of 130ns and 100ns respectively . This fast switching capability enables smooth, precise motor control with minimal switching losses, supporting switching frequencies up to 20kHz in practical applications . The module’s three-phase full-bridge configuration with integrated fast freewheeling diodes ensures optimal commutation performance across the entire operating range.
Robust thermal management: The NINT-45C BSM25GD120DN2 incorporates an insulated metal baseplate that provides excellent thermal transfer to external heatsinks or water-cooling systems . The module supports operation up to a maximum junction temperature of 125°C, with a thermal dissipation capacity of 200W . This robust thermal design enables continuous operation under heavy loads while maintaining long-term reliability. The use of advanced thermal interface materials ensures optimal heat dissipation, preventing performance degradation even in high-ambient-temperature environments .
Industry-standard packaging and reliability: The NINT-45C BSM25GD120DN2 utilizes the EconoPACK 2 package with a 17-pin configuration, ensuring compatibility with a wide range of industrial drive systems and facilitating straightforward replacement or upgrade . The module’s design has been validated through extensive field testing, with guaranteed electrical life of 100,000 cycles and mechanical life of 50,000 hours . This proven reliability, combined with ABB’s rigorous quality control, results in a failure rate significantly below industry standards for power semiconductor modules .
Application Field
Variable frequency motor drives: The NINT-45C BSM25GD120DN2 serves as the core switching element in AC motor drives, including ABB’s ACS800 and ACS880 series frequency inverters. In these applications, the module converts DC bus voltage into variable-frequency AC output to precisely control motor speed and torque. The module’s fast switching characteristics and 1200V blocking voltage make it ideal for controlling induction motors and permanent magnet synchronous motors in industrial machinery .
Industrial power conversion: The NINT-45C BSM25GD120DN2 is deployed in uninterruptible power supplies (UPS), active front-end rectifiers, and regenerative braking systems where bidirectional power flow control is required. The module’s three-phase bridge configuration allows it to handle the high power densities and demanding switching requirements of these applications, ensuring stable power quality and energy recovery .
Renewable energy systems: The NINT-45C BSM25GD120DN2 is used in solar inverter systems, wind turbine converters, and battery energy storage systems, where efficient conversion between DC and AC power is critical. The module’s high efficiency and robust thermal characteristics enable reliable operation in outdoor and harsh environmental conditions commonly encountered in renewable energy installations .
Heavy industrial automation: In sectors such as steel manufacturing, mining, material handling, and paper processing, the NINT-45C BSM25GD120DN2 powers the high-horsepower drives that operate conveyors, crushers, extruders, and other heavy machinery. The module’s proven reliability and long service life are essential for minimizing downtime in continuous production environments .
