Description

Main Features and Advantages

The ABB CI810B offers a wide range of features that make it an essential component for integrating PROFIBUS-based field devices into the AC 800M control system.

Key Features:

PROFIBUS DP V1 Master–Supports advanced features such as acyclic data exchange and diagnostics,enabling real-time control and device monitoring.

High-Speed Communication–Operates at data rates up to 12 Mbps,ensuring fast and efficient data transfer between the controller and field devices.

Support for Multiple Devices–Capable of connecting up to 126 devices per segment,providing flexibility in system design and expansion.

Galvanic Isolation–Ensures protection against electrical interference and ground loops,enhancing system reliability and safety.

DIN Rail Mounting–Designed for easy installation and integration into standard control cabinets.

Redundancy Support–Compatible with redundant AC 800M controller configurations for high availability applications.

Diagnostic Capabilities–Provides detailed diagnostics and error reporting through the AC 800M system,aiding in troubleshooting and maintenance.

Advantages:

Seamless Integration–Works directly with ABB’s AC 800M controllers and Control Builder M software for easy configuration and commissioning.

Scalable Architecture–Enables system expansion through the use of repeaters and multiple segments.

Reliable Performance–Engineered for operation in harsh industrial environments with high electromagnetic interference(EMI).

Backward Compatibility–Supports both DP V0 and DP V1 devices,allowing integration with legacy systems.

Application Fields

The ABB CI810B is widely used across various industries where reliable and high-speed communication between the control system and field devices is essential.

Typical Applications Include:

Power Plants–For communication with turbine control systems,boiler protection devices,and remote I/O stations.

Oil&Gas Facilities–Used in offshore platforms and pipelines for integrating flow meters,pressure transmitters,and control valves.

Chemical and Petrochemical Plants–Facilitates control of reactors,pumps,and batch processes via PROFIBUS-connected devices.

Water and Wastewater Treatment Plants–Connects remote pumping stations,level sensors,and dosing systems to the central control system.

Building Automation–Integrates HVAC systems,fire alarms,and security systems in large commercial and industrial complexes.

Manufacturing and Process Automation–Supports real-time control of production lines,packaging machines,and material handling systems.

Related Products

ABB CI810–Older version of the PROFIBUS DP master module,still used in legacy systems.

ABB CI854–Another PROFIBUS DP V1 Master module with enhanced diagnostics and communication features.

ABB CI840–Communication module for DeviceNet fieldbus protocol.

ABB CI851–Ethernet/IP communication module for connecting Allen Bradley and other EtherNet/IP devices.

ABB PM856–AC 800M controller CPU with integrated PROFIBUS master support.

ABB TB810B–Terminal base for CI810B module with screw or spring-type connections.

ABB SB801–Station bus repeater for extending AC 800M I/O network distance.

ABB DP/PC–PROFIBUS PC interface card for commissioning and diagnostics.

ABB DP/9FMS–PROFIBUS DP/FMS communication module for field-level integration.

ABB DP Repeater–Signal repeater for extending PROFIBUS segments beyond standard length limits.

Pre-installation Preparation

Before installing the ABB CI810B,ensure that the AC 800M control cabinet is powered off and all safety procedures are followed.Verify that the correct terminal base(e.g.,TB810B)is installed and that the PROFIBUS cabling is properly terminated and shielded.Ensure that the station bus is correctly configured and that the AC 800M controller is set up to recognize the CI810B module.Use ABB’s Control Builder M software to configure the communication parameters such as station address,data rate,and connected devices before powering up the system.

Maintenance Recommendations

To ensure long-term performance of the ABB CI810B,perform regular visual inspections for signs of overheating,dust accumulation,or loose connections.Monitor communication diagnostics through the AC 800M system to detect errors such as frame loss,CRC errors,or device timeouts.Periodically verify the PROFIBUS segment configuration and signal quality using a bus analyzer.When replacing the CI810B,always power down the system and follow ESD precautions to avoid damage to sensitive electronics.Keeping a spare module on hand can help reduce downtime during unplanned outages.

Product Guarantee

We guarantee that every ABB CI810B module we supply is 100%original,fully functional,and sourced from authorized ABB distributors or verified OEM channels.Each CI810B undergoes thorough testing and inspection to ensure compliance with ABB’s quality and performance standards.We offer a comprehensive warranty,technical support,and replacement services to ensure your automation system remains operational and efficient.Whether you’re upgrading an existing AC 800M system or commissioning a new process line,the ABB CI810B is backed by our commitment to quality,reliability,and customer satisfaction.
