ABB AC500 Series PM590-ETH Programmable Logic Controller

Description

The ABB PM590-ETH is a high-performance programmable automation controller (PAC) CPU module from ABB’s flagship AC500 series. Designed as a modular and scalable automation core, it combines robust computing power with extensive communication capabilities. With its dual Ethernet ports, onboard LCD display, and support for multiple fieldbus protocols, the PM590-ETH is engineered to handle complex logic, data processing, and network integration in demanding industrial environments such as manufacturing lines, process control, and infrastructure automation.

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Application Scenarios

A large automotive assembly plant faced challenges with its legacy PLC system, which had limited network bandwidth and slow data exchange between welding robots and the central MES. The system could not support real-time production tracking. Engineers deployed the ABB PM590-ETH as the central controller for a new welding station. The module’s dual Ethernet ports enabled seamless integration—one port connected to the plant’s supervisory network for MES data upload, while the other managed a local subnet of robotic controllers and vision sensors. The high-speed processing capability ensured precise coordination of welding guns and part conveyors, while the large memory supported extensive data logging of weld parameters. This upgrade resulted in a 20% increase in station throughput and enabled full traceability of each vehicle body.

Parameter

Parameter	Value / Description
Product Model	ABB PM590-ETH
Manufacturer	ABB
Common Order Number	1SAP150000R0271 (Varies by region/version)
Product Series	AC500 (Medium Performance Tier)
CPU Processor	32-bit High-Performance ARM-based
Program Memory	2 MB (User Program), 3 MB (Data Memory)
Instruction Speed	~0.000002 ms (Bit Instruction)
Onboard I/O	None (Requires external I/O modules via bus)
Communication Ports	2 x Ethernet (10/100 Mbps), 2 x RS232/485 (Configurable), 1 x FBP (FieldBus Plug)
User Interface	Integrated LCD Display + 8 Function Keys
Power Supply	24 V DC (via TB5xx Base Unit)
Operating Temperature	0 °C to +60 °C (Extended: -20 °C to +60 °C)
Mounting	DIN Rail (via TB5xx Terminal Base)
Programming Software	ABB Automation Builder (IEC 61131-3)
Redundancy Support	Yes (System 800xA High Availability)
