ABB 5SHY3545L0009 IGCT Power Module – 4500 V / 3500 A Press-Pack Integrated Gate-Commutated Thyristor for MV Drives

Description

Technical Specifications

Main Features and Advantages

Revolutionary IGCT Technology for Unmatched PerformanceThe ABB 5SHY3545L0009​ embodies the breakthrough IGCT concept that ABB introduced to overcome the limitations of conventional GTO thyristors. By integrating the GCT chip, antiparallel diode, and gate drive circuit into a single low-inductance press-pack assembly, the ABB 5SHY3545L0009​ achieves transistor-like hard turn-off behavior with thyristor-level current carrying capability. This unique combination eliminates the need for bulky, lossy snubber circuits, simplifying inverter design while simultaneously improving efficiency and power density.Ultra-Fast, Snubber-Less SwitchingWith turn-off times in the microsecond range, the ABB 5SHY3545L0009​ delivers switching speeds approximately ten times faster than traditional GTO devices. This rapid switching capability—coupled with low on-state voltage (1.62 V typical)—reduces both switching and conduction losses by up to 50% compared to GTO-based designs. The ABB 5SHY3545L0009​ thereby enables cleaner PWM waveforms, lower harmonic distortion, and higher overall system efficiency exceeding 97% in well-designed converter architectures.Exceptional Surge and Fault Withstand CapabilityThe ABB 5SHY3545L0009​ can withstand non-repetitive surge currents up to 75,000 A, providing critical resilience against severe grid disturbances such as short circuits, lightning strikes, and switching transients. This extraordinary surge capability gives system designers the confidence to deploy the ABB 5SHY3545L0009​ in the most electrically hostile environments, knowing that the module will survive faults that would destroy lesser devices—buying precious time for upstream protection systems to act.Rugged Press-Pack Construction for Ultimate ReliabilityThe ABB 5SHY3545L0009​ employs a sophisticated press-pack design with gold-plated copper busbars and spring-loaded pressure contacts, engineered to endure up to 100,000 thermal cycles without degradation. This mechanical architecture ensures uniform contact pressure, superior thermal management, and excellent resistance to thermal cycling fatigue. Even in the event of partial chip degradation, the press-pack structure enables current redistribution that allows the ABB 5SHY3545L0009​ to continue operating—a fault-tolerant characteristic that dramatically enhances system availability.Integrated Gate Drive and Intelligent ProtectionPaired with the dedicated 3BHB013085R0001​ gate control unit, the ABB 5SHY3545L0009​ benefits from fiber-optic isolated gate signaling that provides exceptional immunity to electromagnetic interference. The gate drive unit delivers precise gate triggering, real-time valve health monitoring, and comprehensive protection against overcurrent, overtemperature, and internal arcing conditions. This intelligent gate interface transforms the ABB 5SHY3545L0009​ from a mere power switch into a smart, self-diagnosing component that communicates its status to the central control system.Superior Thermal ManagementThanks to double-sided cooling capability and the low thermal resistance inherent in press-pack construction, the ABB 5SHY3545L0009​ efficiently dissipates heat from both faces of the semiconductor chip. Whether cooled by forced air or deionized water (with ΔT = 35 °C typical), the module maintains a stable junction temperature across its full −40 °C to +125 °C operating range, ensuring consistent performance even under the most extreme industrial conditions.Seamless Compatibility and Upgrade PathThe ABB 5SHY3545L0009​ is fully compatible with later enhanced revisions including 5SHY35L4510, 5SHY35L4512, and 5SHY35L4520, ensuring seamless integration into both new installations and legacy system upgrades. This backward compatibility protects the long-term investment of power system operators and facilitates phased modernization programs without requiring complete converter redesign.
