ABB 3HAB8101-8/10A DSQC-346G High-Reliability Drive Unit

Description

Application Scenarios

Picture this:a manufacturing line assembling automotive parts using ABB IRB robots.When one robot began misfiring or lagging,engineers swapped in a 3HAB8101-8/10A DSQC346G module on the fly—and bam!The axis seized back up,synchronized perfectly again.This module saved the line from a production halt.That’s the real-world muscle this unit brings—trusted when uptime absolutely cannot slip.

Main Parameters

Main Parameters Value/Description

Product Model 3HAB8101-8/10A DSQC346G

Manufacturer ABB

Product Category Servo Drive Amplifier/Robot Axis Control Module

Supported Robot Series ABB IRB series with S4C/S4C+controller

Application One-axis servo control

Mounting Module rack slot within robot control cabinet

Module Weight Approx.3.14 kg

Country of Origin Ireland

Dimensions(estimate)Approx.13 cm×2 cm×19 cm

Moore Automation Limited

Replacement Part No.E-3HAB8101-8(new replacement)

Runto Electric

Technical Principles and Innovative Values

Innovation Point 1:Specialized for ABB IRB robot control systems,ensuring seamless axis-level motion control with minimal latency.

Innovation Point 2:Rugged module design supports hot-swapping—swap it without shutting down the whole machine.

Innovation Point 3:Built-in compatibility with both S4C and S4C+controller platforms ensures future-proof flexibility.

Innovation Point 4:Compact footprint maximizes cabinet space—handy when you’re juggling multiple axes and modules.

Application Cases and Industry Value

Case 1–Automotive Assembly

At a high-speed car assembly plant,a failing DSQC346G module caused a slow-down on a critical axis.Swap it out with a fresh 3HAB8101-8/10A DSQC346G,and the robot pivoted back into rhythm immediately.Output improved,errors vanished,and nobody had to pull an all-nighter.

Case 2–Electronics Manufacturing

An electronics manufacturer retrofitted legacy S4C robots and found the old servo drives couldn’t keep up with tighter electronic gluing precision.Replacing them with brand-new 3HAB8101-8/10A DSQC346G modules not only improved repeatability but also shaved maintenance time by 30%.

Related Product Combination Solutions

These ABB modules often travel together in harmony:

ABB DSQC 346G(3HAB8101-8)–Non“/10A”variant compatible with similar robots.

ABB 3HAC026253-001 DSQC661–Power supply module for robot systems.

ABB DSQC 647 I/O Interface Module–Handles peripheral communication like sensors and lights.

ABB DSQC 678 Axis Computer Module–For advanced multi-axis motion coordination.

ABB DSQC 647A Teach Pendant Interface Module–Connect your teach pendant ergonomically.

Installation,Maintenance,and Full-Cycle Support

This ABB 3HAB8101-8/10A DSQC346G module drops into the ABB robot’s control cabinet.Prepped cabinets,firm backplane rails—it clicks in and powers up.Keep spare modules on hand;the design allows swapping without full power-down,slashing turnaround for repairs.

Routine maintenance?Keep contacts clean,watch thermal conditions inside the cabinet,and firmware up to date.ABB(and partners like Shenzhen Changxin)stand by with replacements,calibration support,and logistics to get your bot back online ASAP.
