Product Overview

The ABB 3BHB003387R0101is a high-performance Integrated Gate-Commutated Thyristor(IGCT)power semiconductor device designed for medium-voltage drive applications and industrial power conversion systems.This advanced power electronic component represents ABB’s cutting-edge technology in high-power electronics,providing efficient switching capabilities for demanding industrial applications.The 3BHB003387R0101exemplifies ABB’s leadership in power electronics through its robust construction and reliable performance in high-power conversion systems where switching efficiency and reliability are critical for operational success.

Engineered with state-of-the-art semiconductor technology,the ABB 3BHB003387R0101delivers superior switching characteristics and high current-handling capabilities for various power conversion applications.The device’s innovative packaging and cooling design ensure optimal thermal performance under high-power conditions,while the integrated gate drive unit simplifies system integration.Implementation of the 3BHB003387R0101in power conversion systems demonstrates ABB’s expertise in creating efficient and reliable solutions for industrial drives,renewable energy systems,and power quality applications.

Technical Specifications

Parameter Name

Parameter Value

Product Model

3BHB003387R0101

Manufacturer

ABB

Product Type

IGCT(Integrated Gate-Commutated Thyristor)

Voltage Rating

4500V

Current Rating

4000A(maximum)

Switching Frequency

Up to 500Hz

Gate Drive

Integrated gate driver

Operating Temperature

-40°C to+125°C

Storage Temperature

-40°C to+125°C

Isolation Voltage

6000V AC

Mounting

Press-pack design

Cooling Method

Liquid cooling

Weight

2.8kg

Certifications

UL,CE,IEC

Main Features and Advantages

Advanced Semiconductor Technology:The ABB 3BHB003387R0101utilizes state-of-the-art IGCT technology that combines the advantages of GTO thyristors and IGBTs.This innovative design provides low conduction losses and snubberless operation,making it ideal for high-power applications.The device’s symmetrical voltage blocking capability and high di/dt rating ensure reliable performance in demanding industrial environments.These characteristics make the 3BHB003387R0101particularly suitable for high-power conversion systems where efficiency and reliability are paramount.

Robust Thermal Management:Engineered for high-power applications,the ABB 3BHB003387R0101features an advanced press-pack design that ensures efficient heat dissipation.The double-sided cooling capability allows for effective thermal management,enabling operation at high current densities.The device’s wide operating temperature range from-40°C to+125°C ensures reliable performance in various environmental conditions,while the robust construction provides mechanical stability under thermal cycling stresses.

Integrated Protection System:The ABB 3BHB003387R0101incorporates comprehensive protection features including overcurrent protection,overvoltage protection,and temperature monitoring.These built-in protection mechanisms significantly enhance system safety and extend the device’s service life.The integrated gate driver provides optimal switching characteristics while ensuring protection against abnormal operating conditions.

Application Field

In industrial drive systems,the ABB 3BHB003387R0101is extensively used in medium-voltage variable speed drives for high-power motors.The device’s high switching capability and reliability ensure efficient motor control in applications such as rolling mills,mine hoists,and large pump systems.In metal processing plants,the 3BHB003387R0101provides precise power control for critical processes,contributing to energy efficiency and process optimization.

Power generation and renewable energy applications utilize the ABB 3BHB003387R0101in high-power converters for wind turbines,solar farms,and grid connection systems.The device’s high voltage rating and robust design make it suitable for demanding renewable energy applications where reliability and efficiency are crucial.Multiple installation projects demonstrate the 3BHB003387R0101’s suitability for applications requiring long-term reliability with minimal maintenance.
