ABB 3AXD50000711901 2MBI1000VXB-170E-50 IGBT Module

Description

​Product Description​​

The​​ABB 3AXD50000711901 2MBI1000VXB-170E-50​​is a high-power dual IGBT module designed for industrial power conversion applications.This advanced power semiconductor module features two IGBTs with anti-parallel diodes,providing efficient switching capabilities for high-power inverters,converters,and motor drives.Its robust construction and advanced semiconductor technology make it suitable for demanding industrial applications requiring reliable power control.

Voltage Rating:1700V

Current Rating:1000A

Configuration:Dual IGBT with diodes

Package:Module

​​Application Scenarios​​

In a steel mill’s main rolling mill drive system,the​​ABB 3AXD50000711901 2MBI1000VXB-170E-50​​IGBT modules were implemented in the high-power frequency converters controlling the main drive motors.The modules’high current capacity and voltage rating enabled efficient control of multi-megawatt motors,while their robust thermal performance ensured reliable operation under heavy load conditions.The​​2MBI1000VXB-170E-50​​modules’durability reduced unexpected downtime by 40%compared to previous power semiconductor solutions,significantly improving production efficiency.

​​Technical Parameters​​

Parameter

Specification

​​Product Model​​

2MBI1000VXB-170E-50

​​Order Code​​

3AXD50000711901

​​Manufacturer​​

ABB

​​Product Category​​

IGBT Power Module

​​Voltage Rating​​

1700V VCES

​​Current Rating​​

1000A IC(25°C)

​​Configuration​​

Dual IGBT with diodes

​​Switching Frequency​​

Up to 20kHz

​​Isolation Voltage​​

4000V RMS

​​Module Technology​​

Press-Fit/Solder

​​Weight​​

Approximately 800g

​​Storage Temperature​​

-40°C to+125°C

​​Operating Temperature​​

-40°C to+150°C(Tj)

​​Certifications​​

UL,CE

​​Technical Principles and Innovative Values​​

Innovation Point 1:The​​ABB 3AXD50000711901 2MBI1000VXB-170E-50​​utilizes advanced trench gate IGBT technology that provides low saturation voltage and minimal switching losses.This technology enables high-efficiency power conversion while maintaining excellent thermal performance.The module’s optimized internal layout minimizes parasitic inductance,reducing voltage overshoot during switching transitions and enhancing system reliability.

Innovation Point 2:Featuring a robust pressure contact technology and advanced substrate design,the module offers superior thermal cycling capability and mechanical stability.The integrated temperature sensor provides accurate junction temperature monitoring,enabling advanced thermal management and protection functions.The module’s symmetrical layout ensures balanced current sharing between parallel chips,maximizing current handling capability and reliability.

​​Application Cases and Industry Value​​

Case Study:A wind turbine manufacturer integrated the​​ABB 3AXD50000711901 2MBI1000VXB-170E-50​​modules into their multi-megawatt power converters.The modules’high reliability and efficiency contributed to a 2%increase in overall energy conversion efficiency,translating to significant additional power generation over the turbine’s lifetime.The robust design withstood the demanding environmental conditions,reducing maintenance requirements and improving system availability.

​​Related Product Combination Solutions​​

​​ABB Gate Driver Units​​-Compatible driving circuits

​​ABB Heat Sinks​​-Thermal management solutions

​​ABB DC-Link Capacitors​​-Power circuit components

​​ABB Current Sensors​​-Monitoring and protection devices

​​ABB Power Supplies​​-Auxiliary power units

​​Installation and Maintenance​​

Installation Preparation:The​​ABB 3AXD50000711901 2MBI1000VXB-170E-50​​requires proper thermal interface material application and precise mounting torque.Ensure clean,flat mounting surfaces and use recommended thermal compounds.Follow strict ESD precautions during handling and installation.

Maintenance Protocol:Regular thermal imaging inspections help identify potential cooling issues.Monitor module temperature during operation and maintain clean cooling systems.Implement predictive maintenance based on operational hours and thermal cycling history.

Technical Support:Our team provides comprehensive support including thermal design,application engineering,and failure analysis services.

​​Product Assurance​​

The​​ABB 3AXD50000711901 2MBI1000VXB-170E-50​​is manufactured to the highest quality standards and backed by ABB’s technical expertise in power semiconductors.
