Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 719-100G |
| Manufacturer | Fluke Corporation |
| Product Type | Electric Pressure Calibrator |
| Pressure Range | -12 to 120 psi (-850 mbar to 8 bar) -2-6 |
| Pressure Resolution | 0.01 psi (1 mbar) -4-6 |
| Pressure Accuracy | 0.025% of range (6 months), 0.035% of range (1 year) -6-11 |
| mA Range | 0 to 24 mA -3-6 |
| mA Resolution | 0.001 mA -6-11 |
| mA Accuracy | ±(0.015% reading + 2 counts) -3-11 |
| Loop Supply Voltage | 24 V DC ±10% -11 |
| Maximum Pump Pressure | 120 psi (8 bar) -6-11 |
| Pump Speed | -100 psi in <45 seconds (with 1 meter hose) -6-11 |
| Operating Temperature | -10°C to 55°C -2-6 |
| Storage Temperature | -30°C to 60°C -1-5 |
| Humidity | 95% (-10°C to 30°C), 75% (30°C to 40°C) -6-11 |
| Battery Life | ~12 hours with 12 mA load, ~200 pump cycles to 100 psi -1-5 |
| Safety Certification | CSA C22.2 No. 1010.1:1992 -1-5 |
| EMC Compliance | EN50082-1:1992, EN55022:1994 Class B -1-5 |
| Dimensions (H×W×L) | 60 × 87 × 210 mm (2.19 × 3.41 × 8.28 in) -1-5 |
| Weight | 912 g (2 lb) -1-5 |
Main Features and Advantages
Built-in electric pump for one-handed operation: The FLUKE 719-100G features an innovative, integrated electric pump that eliminates the physical strain and time consumption of manual hand pumping. This unique design allows technicians to generate pressure with the push of a button while using their other hand to adjust the device under test or record data -1-7. The programmable pump limit function prevents over-pressurization and enables the user to program target pressures for automatic pumping, significantly reducing calibration time and improving consistency. The pump can generate -30 psi in less than 15 seconds and -100 psi in less than 45 seconds, ensuring rapid pressurization for efficient workflow -6-11.
Exceptional measurement accuracy and precision: The FLUKE 719-100G provides best-in-class pressure measurement uncertainty of 0.025% full span and mA measurement accuracy of 0.015% reading plus 2 counts -4-6. The precision pressure adjust vernier allows fine adjustment of pressure with exceptional resolution, while the variable release rate bleed valve enables smooth and controlled pressure reduction during calibration -1-4. This combination of high accuracy and fine control makes the FLUKE 719-100G ideal for calibrating high-precision pressure transmitters and other critical process instrumentation.
Versatile mA loop functionality: The FLUKE 719-100G simultaneously measures pressure and sources or simulates mA signals, enabling comprehensive testing of valves, I/P transducers, and complete 4-20 mA loops -4-7. The built-in 24 V loop supply powers transmitters during testing without requiring external power sources, making field calibration completely self-contained. The HART compatibility with 750 Ω load capability supports modern smart transmitter configuration and troubleshooting -6-11.
Robust design for field use: Built to withstand the rigors of industrial environments, the FLUKE 719-100G is tested to survive a 1-meter drop and operates reliably across a wide temperature range of -10°C to 55°C -1-5. The unique cleanout ports allow easy removal of moisture, debris, or fluid contamination that could otherwise damage the pump mechanism, significantly reducing pump failures and maintenance costs -4-6. This rugged design, combined with a 3-year warranty on the calibrator (1 year on the pump), provides long-term reliability and peace of mind
