Product Overview

The O-63007 (also referenced as 0-63007, M003742626, or 803624-113) is a high-performance permanent magnet synchronous servo motor manufactured by ABB, designed for precision motion control applications in robotics and industrial automation . This motor is part of ABB’s 0-63 series framework, a compact servo motor family commonly deployed in ABB IRB series industrial robots, particularly the IRB 140 and IRB 240, where it serves as the drive unit for individual joint axes or independent positioning stations . The multiple part numbers—O-63007, M003742626, and 803624-113—represent different manufacturer catalog identifiers and batch designations for the same fundamental motor platform.

Engineered as a three-phase permanent magnet synchronous motor (PMSM), the O-63007 is built to deliver precise torque and speed control with high dynamic response, making it ideal for applications requiring accurate positioning and smooth motion . The motor typically features an absolute encoder for closed-loop feedback, with protocol options including Hiperface, EnDat, or resolver, depending on the production era and specific bill of materials . An electromagnetic spring-applied brake (24V DC control) is optionally available for holding applications where load retention is required during power-off conditions . The O-63007 is compatible with ABB ACSM1 servo drive units and ABB IRC5 cabinet servo modules (DSQC series), facilitating seamless integration into ABB’s automation ecosystem .





Technical Specifications

Parameter Name	Parameter Value
Product Model	O-63007 / 0-63007
Manufacturer	ABB
Product Type	Permanent Magnet Synchronous Servo Motor (PMSM)
Other Part Numbers	M003742626, 803624-113
Motor Type	Three-Phase Permanent Magnet Synchronous Servo Motor
Rated Power	0.2 – 1.0 kW (typical 0.4 – 0.75 kW, variant-dependent)
Rated Speed	3000 rpm (typical)
Maximum Speed	4500 – 6000 rpm (winding-dependent)
Rated Torque	0.7 – 3.0 N·m (continuous)
Peak Torque	2 – 3× rated torque
Rated Voltage	Three-Phase 220V AC (320V DC link)
Encoder Type	Absolute Encoder (Hiperface / EnDat / Resolver, variant-dependent)
Brake Option	Optional Electromagnetic Spring Brake (24V DC, hold type)
Frame Size	Approx. 60mm square (O-63 series)
Protection Class	IP54 (Standard) / IP65 (Sealed Shaft Option)
Insulation Class	Class F or H (year-dependent)
Cooling Method	Natural Convection (IC410) / Forced Air (IC411, larger frames)
Mounting Type	Flange Mount (IM3001)
Operating Temperature	-15°C to +40°C (ambient)
Weight	1.5 – 4.0 kg (depending on brake option and frame)
Compatibility	ABB ACSM1, ABB IRC5 DSQC servo modules





Main Features and Advantages

Advanced permanent magnet synchronous technology: The O-63007 employs permanent magnet synchronous motor (PMSM) design, delivering superior torque density and efficiency compared to traditional induction motors. This technology enables smooth, cogging-free operation with excellent dynamic response, making the O-63007 particularly suitable for robotic applications requiring precise position control and minimal torque ripple . The motor’s high power-to-weight ratio contributes to compact machine designs without sacrificing performance.

Flexible encoder and feedback options: The O-63007 supports multiple absolute encoder protocols, including Hiperface, EnDat, and resolver, offering compatibility with a broad range of servo drive systems . This flexibility allows the O-63007 to be configured for different control architectures while providing precise position and velocity feedback essential for closed-loop motion control. The absolute encoder maintains position information even after power loss, eliminating the need for homing sequences in many applications.

Robust construction with optional brake: The O-63007 features a rugged housing with IP54 standard protection, with an IP65 option available for applications requiring enhanced sealing against dust and moisture ingress . The optional 24V DC electromagnetic spring brake provides fail-safe holding torque, securing the load when power is removed, which is critical for vertical axes and safety-critical positioning applications .

Integrated thermal management: With Class F or H insulation systems, the O-63007 is rated for winding temperatures up to 155°C, ensuring reliable operation under high-duty cycles . The motor’s cooling design accommodates both natural convection and forced air cooling configurations, adapting to varying thermal demands across different applications. This thermal robustness extends the O-63007 operational life and reduces the risk of premature failure in demanding industrial environments.
