Technical Specifications
| Parameter Name | Value |
|---|---|
| Product Model | 1TGE120026R0103 |
| Manufacturer | ABB |
| Product Type | MView Industrial Touch Screen Panel / HMI |
| Screen Size | 10.4-inch TFT Color LCD |
| Display Resolution | 800 × 600 (SVGA) |
| Touch Technology | Resistive (glove-compatible, oil-resistant) |
| Processor | ARM Cortex-A8, 800MHz |
| Memory | 512MB RAM / 256MB Flash |
| Power Supply | DC 24V (18–32V wide range) |
| Power Consumption | ~12W |
| Communication Ports | RS232/RS485/RS422 (DB9), RS485 (RJ45), Ethernet, USB Host |
| Supported Protocols | Modbus RTU, ABB Drive/Excitation Protocols |
| Front Panel Protection | IP65 (dust-tight, water-resistant) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Cutout Dimensions | Standard control cabinet mounting |
Main Features and Advantages
Reliable Operation in Harsh Industrial Environments: The ABB 1TGE120026R0103 is purpose-built for the rigors of the plant floor. Its resistive touch screen remains fully functional even when operators are wearing heavy work gloves, and its surface resists performance degradation from oil, grease, and dust. The front panel’s IP65 rating ensures protection against water jets and dust ingress, making the 1TGE120026R0103 suitable for installation on switchgear doors and control consoles in demanding settings such as steel mills, water treatment plants, and chemical facilities. The board’s conformal coating further protects internal electronics from corrosive atmospheres and conductive contaminants.
Seamless Integration with ABB Automation Ecosystems: A key advantage of the ABB 1TGE120026R0103 is its native compatibility with ABB’s extensive automation and power distribution product lines. It communicates directly with the M10x series motor controllers used in MNS iS switchgear, allowing a single 1TGE120026R0103 to monitor and control up to 60 motor starters on a single RS485 segment. The panel also supports ABB’s proprietary protocols for ACS drives and UNITROL excitation systems, providing a unified operator interface for diverse equipment without complex configuration. For integration into non-ABB control systems, the 1TGE120026R0103 supports Modbus RTU and features Ethernet for SCADA connectivity.
Comprehensive Monitoring and Diagnostics: The ABB 1TGE120026R0103 provides operators with full visibility into equipment health and performance. It displays real-time trends of key variables such as motor current, voltage, power factor, and thermal load, and it logs historical data and alarm events with timestamps. The panel includes a multi-level password system, allowing different access rights for operators, engineers, and administrators to prevent unauthorized parameter changes. In the event of a fault, the 1TGE120026R0103 displays pop-up alarms with diagnostic codes and allows operators to perform local resets and start/stop commands directly from the cabinet door, significantly reducing troubleshooting time and improving mean time to repair (MTTR).
