Product Overview

The ABB 1SVR730010R3200, identified by its type designation CT-MBS.22S, is a versatile multifunction electronic time relay from ABB’s renowned CT-S timer range, engineered for precise timing control in industrial automation and commercial applications . As a 2C/O (DPDT) relay, the ABB 1SVR730010R3200 provides two changeover contacts rated at 250V/4A, offering exceptional flexibility for controlling auxiliary circuits, motor starting sequences, and process timing functions . The ABB 1SVR730010R3200 is designed with a broad universal control supply voltage of 24-48V DC and 24-240V AC, making it compatible with a wide range of control systems without requiring separate power supply modules .

The ABB 1SVR730010R3200 CT-MBS.22S supports 10 selectable timing functions and 10 time ranges from 0.05 seconds to 300 hours, enabling it to address virtually any timing requirement in industrial control panels . The device features a floating (volt-free) control input, allowing it to be triggered by a simple contact closure without needing a separate trigger voltage . A remote potentiometer connection is also provided for fine adjustment of the time delay . The ABB 1SVR730010R3200 is housed in a 22.5mm wide enclosure that snaps onto standard DIN rails, with screw connection technology employing double-chamber cage connection terminals for secure and reliable wiring .
