Product Overview
The ALLEN-BRADLEY 1203-CN1 is a dedicated ControlNet communications module designed to serve as a high-performance network interface between the ControlNet industrial control network and a single SCANport-enabled device-1-4. This specialized ALLEN-BRADLEY 1203-CN1 module allows any SCANport-equipped member of the Allen-Bradley standard drives family—including the popular 1336 PLUS and other adjustable frequency drives—to be seamlessly connected to a ControlNet network, enabling advanced control, monitoring, and data exchange capabilities-2-5. As a cornerstone of legacy Rockwell Automation distributed control architectures, the ALLEN-BRADLEY 1203-CN1 provides deterministic I/O control and unscheduled messaging, leveraging ControlNet’s open communication protocol features such as redundant media support and real-time data exchange-9.
The ALLEN-BRADLEY 1203-CN1 module bridges the gap between SCANport peripherals and modern industrial networks, offering substantial operational benefits including high-speed I/O control and the ability to perform explicit messaging to access drive parameters and status data. Supporting both CIP (ControlNet Information Protocol) and PCCC (Programmable Controller Communication Commands) messaging, the ALLEN-BRADLEY 1203-CN1 is compatible with a wide range of controllers, from legacy PLC-5 systems to modern ControlLogix platforms-3-5. Its rugged design, DIN rail mounting capability, and comprehensive status indicators ensure reliable performance in demanding industrial environments-2-5. Today, the ALLEN-BRADLEY 1203-CN1 remains a critical component for maintaining operational continuity in automation systems where the SCANport to ControlNet interface is essential for drive control and process monitoring-2-9.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 1203-CN1 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Type | ControlNet Communications Module |
| Product Family | 1203 Communication Modules |
| Network Protocol | ControlNet (Coax Network Port) |
| SCANport Support | Single Device |
| Power Supply | 24V DC (-20% / +30%) |
| Power Consumption / Current Draw | 250 mA at 24V DC -1-4-8 |
| Communication Interfaces | ControlNet coax port, RS-232 serial port -4-5 |
| Mounting Method | DIN Rail (35 x 7.5 mm standard) -1-2-8 |
| Status Indicators | Bi-color LEDs (Module, Network, SCANport) -1-4-9 |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) -1-8 |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) -8 |
| Operating Humidity | 5% to 80% non-condensing -8 |
| Shock (Operating) | 30g peak acceleration, 11 ms pulse -8 |
| Vibration (Operating) | 2.5g @ 5Hz-2KHz -8 |
| Dimensions (L×W×H) | 3.92 × 2.69 × 3.54 in (99.5 × 68.4 × 90.0 mm) -2-8 |
| Weight | 0.52 lbs (236.7 g) -2-4-8 |
| Regulatory Approvals | UL 508, cUL, CE (EMC & Low Voltage Directives) -8 |
| ESD Susceptibility | 6KV contact, 8KV open air (IEC 1000-4-2) -8 |
| Serial Port Baud Rate | 9600 bps (configurable to 19.2 kbps) -5 |
