Application Scenarios:
In a packaging line, multiple 22B‑D4P0N104 drives control the speed of conveyor sections and a filler pump. The built‑in PID function allows the pump drive to maintain a constant pressure based on a 4–20 mA sensor signal, while the conveyor drives use preset speeds via digital inputs. The RS‑485 network enables a central PLC to monitor run status and change speeds without extensive analog wiring.
Parameter:
| Main Parameters | Value/Description |
|---|---|
| Catalog Number | 22B‑D4P0N104 (PowerFlex 40 Series) |
| Manufacturer | Allen‑Bradley (Rockwell Automation) |
| Rated Power | 1.5 kW (2 HP) |
| Input Voltage | 380–480 V AC, 3‑Phase, 50/60 Hz |
| Output Current | 4.0 A Continuous |
| Overload Capacity | 150% for 60 seconds (Normal Duty) |
| Control Modes | V/Hz, Sensorless Vector Control |
| Enclosure | IP20 (Open Type), Frame B |
| Mounting | Panel Mount or 35 mm DIN Rail |
| Keypad | Integrated LED Display & Fixed Keypad |
| Communication | Built‑in RS‑485 (DSI), supports Modbus RTU |
| I/O Capability | 3 Digital Inputs, 2 Analog Inputs (0–10V/4–20mA), Relay Output |
| Built‑in Features | PID Controller, DC Injection Braking, Auto‑tune |
| Operating Temp. | 0 °C to +50 °C (derating above 40 °C) |
| Certifications | UL, cUL, CE (non‑filter version typical) |
Technical Principles and Innovative Values:
- Innovation Point 1: Sensorless Vector Performance in a Compact Frame. Unlike basic V/Hz drives, the 22B‑D4P0N104 implements Sensorless Vector Control without requiring a motor feedback encoder. It uses advanced algorithms to estimate motor flux, providing high starting torque (up to 150% at low speeds) and improved speed regulation. This allows it to handle applications with varying loads, such as a conveyor lifting a product, without the cost and complexity of an encoder feedback card.
- Innovation Point 2: Embedded PID for Standalone Process Control. The drive includes a fully functional PID controller in firmware. This allows it to act as a standalone process loop regulator. For example, in a ventilation system, the drive can directly read a pressure transducer signal (via its analog input), compare it to a setpoint, and automatically adjust the fan speed to maintain constant static pressure, eliminating the need for an external PLC or controller.
- Innovation Point 3: DSI (Drive Serial Interface) Expandability. The integrated RS‑485 DSI port is more than just a Modbus interface; it is a platform for plug‑in communication adapters (e.g., 22‑COMM series for EtherNet/IP, DeviceNet). This modular design allows the same base drive to be upgraded from standalone use to integrated network node status without hardware replacement, protecting investment.
