Description

The 140CPS12400 is a high-availability, redundant-capable power supply module developed by Schneider Electric for the Modicon Quantum programmable automation controller (PAC) platform. Designed for mission-critical industrial applications in water/wastewater, energy, mining, and manufacturing, this 115/230 VAC input, 24 VDC output power supply delivers up to 10 A of continuous current with hot-swap capability, integrated diagnostics, and seamless failover support in redundant backplane configurations. The 140CPS12400 ensures uninterrupted operation of I/O modules, CPUs, and communication processors—even during power unit failure or maintenance—making it essential for systems requiring maximum uptime and process continuity.

Engineered to meet industrial safety and reliability standards, it features overvoltage, overcurrent, and short-circuit protection, along with real-time status monitoring via front-panel LEDs and remote signaling through the Quantum backplane.

Application Scenarios

At a major metropolitan water treatment plant in California, a single-point power failure in a non-redundant PLC system caused a 4-hour shutdown of chemical dosing pumps, triggering regulatory violations and emergency response protocols. After upgrading to a dual-redundant Modicon Quantum rack equipped with two 140CPS12400 modules, the facility achieved true fault tolerance: when one power supply failed during a voltage sag event, the second instantly assumed full load without disrupting control logic or I/O scanning. Over three years, the plant recorded zero power-related outages. Operators now refer to the 140CPS12400 as the “silent guardian” of public health compliance—proving that in critical infrastructure, power resilience isn’t optional, it’s foundational.



Technical Principles and Innovative Values

Innovation Point 1: True Load-Sharing Redundancy – When two 140CPS12400 modules are installed in a Quantum redundant backplane, they actively share the system load (~5 A each). If one fails, the other seamlessly supplies full 10 A—eliminating brownout risks during transition, unlike simple backup designs.

Innovation Point 2: Backplane-Integrated Diagnostics – The 140CPS12400 reports real-time status (voltage, current, fault codes) directly to the Quantum CPU via the backplane, enabling remote monitoring in Unity Pro or EcoStruxure™ Control Expert—no external wiring needed.

Innovation Point 3: Universal AC Input with High Efficiency – With auto-ranging 85–264 VAC input and >85% efficiency, the 140CPS12400 operates reliably across global grids while minimizing heat generation and energy waste.

Innovation Point 4: Industrial-Ruggedized Design – Conformal-coated PCBs, wide temperature tolerance, and surge immunity per IEC 61000-4-5 make the 140CPS12400 suitable for harsh environments—from desert pump stations to underground mines.

Application Cases and Industry Value

A copper mine in Chile deployed redundant Modicon Quantum systems with dual 140CPS12400 units to control conveyor and crusher operations in a high-altitude, dust-laden environment. During a monsoon-induced grid fluctuation, one power supply tripped due to an internal fan fault. The second 140CPS12400 maintained full system operation, allowing maintenance to replace the faulty unit during the next shift—avoiding an estimated $380K/hour production loss. Over five years, the mine reported 99.998% system availability, directly attributing reliability to the robustness of the 140CPS12400 power architecture.

Related Product Combination Solutions

140CPU67160: High-performance Quantum CPU—relies on stable 24 VDC from the 140CPS12400 for deterministic control

140CRP93x00: Redundant backplane—required to enable N+1 operation of dual 140CPS12400 modules

140DDI35300 / 140DDO35300: Digital I/O modules—powered entirely by the 140CPS12400 in standard or redundant racks

140NOM21200: Ethernet/IP communication module—depends on clean, uninterrupted power from the 140CPS12400 for SCADA connectivity

140CPS11420: 8 A non-redundant variant—suitable for simplex applications where cost is prioritized over fault tolerance

Schneider Electric Unity Pro / EcoStruxure Control Expert: Programming software—displays 140CPS12400 diagnostics in real time for predictive maintenance

140XBP00600: Baseplate extender—enables flexible placement of 140CPS12400 in large I/O configurations

Installation, Maintenance, and Full-Cycle Support

Installation of the 140CPS12400 requires mounting into a compatible Modicon Quantum backplane (standard or redundant), connecting AC input via terminal block or conduit, and ensuring proper ventilation clearance (minimum 50 mm on sides). In redundant setups, both modules must be of the same model and firmware revision. The system automatically synchronizes load sharing upon power-up.

For maintenance, front-panel LEDs provide immediate visual status: green = normal, red = fault (e.g., overtemp, short circuit). Thanks to hot-swap support, failed units can be replaced during live operation—minimizing downtime. Each 140CPS12400 undergoes 100% burn-in testing and complies with Schneider’s 10-year lifecycle commitment for Quantum components. Our certified engineers offer pre-deployment power budget analysis, redundancy validation, and spare strategy planning—ensuring your 140CPS12400 delivers decades of dependable service in the world’s most demanding automation environments.
