Description​

The GE IC698PSA100E​ is a robust 100-watt industrial power supply module manufactured by General Electric (now part of Emerson Automation) for the PACSystems RX7i platform . It serves as the core power unit for RX7i control systems, converting AC or DC input into stable 24V DC power to support CPUs, I/O modules, and communication cards . Designed for critical applications, it features hot-swap capability, redundant configurations, and compliance with IEC 61010 safety standards, ensuring reliability in demanding environments like power generation and chemical processing .

Application Scenarios​

In a chemical plant’s polymerization reactor control system, a sudden power supply failure could trigger an emergency shutdown, risking material loss and safety hazards. Here, the GE IC698PSA100E​ demonstrates its value through a redundant setup: two modules operate in parallel, with one seamlessly taking over if the other fails. This design prevented a reactor shutdown during a grid fluctuation at a large LNG facility, avoiding $2M in potential losses . Such scenarios underscore the module’s role in ensuring zero-interruption power for continuous processes .

Parameter​

Technical Principles and Innovative Values​

Active Current Sharing and Redundancy: The IC698PSA100E​ uses parallel architecture with active current balancing, allowing dual modules to share loads equally. If one fails, the other assumes full power within milliseconds (<5ms switching time), eliminating downtime .

Fanless Thermal Management: Its natural convection cooling eliminates fans, reducing failure points and maintenance needs while operating at up to 60°C ambient temperature .

Wide Input Voltage Range: Accepts 85–264V AC or 100–300V DC, enabling global deployment without external converters .

Integrated Diagnostics: LED indicators and Proficy Machine Edition software integration provide real-time health monitoring, enabling predictive maintenance .

Application Cases and Industry Value​

A natural gas liquefaction (LNG) plant integrated redundant GE IC698PSA100E​ modules into its compressor anti-surge control system. Over three years, the setup endured multiple grid disruptions without shutdowns, safeguarding against $2M-per-incident losses. The plant manager noted: “The redundancy of the IC698PSA100E​ ensured continuous operation during power dips, directly protecting revenue and safety”. This highlights the module’s value in critical infrastructure where reliability translates to risk mitigation .

Related Product Combination Solutions​

RX7i CPUs (e.g., IC698CRE020): Directly powered by the IC698PSA100E, executing control logic .

I/O Modules (e.g., IC694MDL655): Rely on the 24V DC output for sensor/actuator interfacing .

Communication Cards (e.g., IC695ETM001): Enable network integration using stable power from the module .

Redundant Baseplates (e.g., IC698CH001): Facilitate hot-swap functionality for N+1 configurations .

Installation, Maintenance, and Full-Cycle Support​

Installation: Mount the IC698PSA100E​ in the leftmost slot (Slot 0) of an RX7i rack, connecting AC/DC input to terminal blocks. Verify “Power OK” LEDs and configure redundancy via Proficy Machine Edition .

Maintenance: Hot-swap capability allows module replacement without shutdown. Perform biannual checks of LED status and airflow, and replace electrolytic capacitors after 7 years for optimal longevity .

Support: Suppliers offer 12-month warranties, technical assistance for power budgeting, and lifecycle management for obsolescence planning .
