Description

The CC-PDOB01 is a 16-channel, solid-state digital output module engineered by Honeywell for the Experion® Process Knowledge System (PKS) and Safety Manager platforms. Designed for high-reliability process and safety applications, it provides isolated, sourcing-type transistor outputs to drive field devices such as solenoid valves, relays, motor starters, and visual alarms with precise timing and diagnostic visibility.

Built for continuous operation in harsh industrial environments—from offshore platforms to pharmaceutical cleanrooms—the CC-PDOB01 combines functional safety compliance (IEC 61508 SIL2), hot-swap capability, and per-channel fault protection to ensure operational integrity where every output command matters.

Application Scenarios

At a petrochemical plant in Texas, a reactor emergency depressurization system relied on fast, fail-safe actuation of multiple blowdown valves. Engineers selected the Honeywell CC-PDOB01 within a redundant Experion Safety Manager architecture to energize 24VDC pilot solenoids. During a full-scale safety test, all 16 outputs triggered within 3 ms—well below the 50 ms safety window—successfully isolating the vessel before overpressure occurred. Months later, when a short circuit developed in one field solenoid, the CC-PDOB01’s intelligent current limiting disabled only the affected channel while maintaining all others active, preventing an unnecessary plant trip. For industries where a single failed output can risk lives or millions in assets, the CC-PDOB01 delivers not just switching—but assured action.

Parameter

表格

Technical Principles and Innovative Values

Innovation Point 1: Per-Channel Electronic Protection

Unlike relay-based or fused outputs, the CC-PDOB01 uses intelligent semiconductor switches that detect overloads or shorts and disable only the faulty channel—keeping the remaining 15 outputs fully operational.

Innovation Point 2: True Hot-Swap in Redundant Systems

When installed in a dual-redundant C300 chassis, the CC-PDOB01 supports live replacement: the controller maintains output state during module extraction and reinsertion, ensuring zero process interruption.

Innovation Point 3: SIL2-Certified Determinism

Validated for use in Honeywell Safety Manager, the CC-PDOB01 provides auditable proof of compliance with functional safety lifecycle requirements—essential for ESD, BMS, and fire & gas shutdown logic.

Innovation Point 4: Deep Integration with Experion Ecosystem

Output status, faults, and diagnostics appear natively in Experion Operations and Studio—no third-party drivers or OPC tunnels needed. Alarms propagate instantly to HMI and historian.

Application Cases and Industry Value

In a biologics manufacturing facility in Switzerland, the CC-PDOB01 controls HVAC isolation dampers and sterilization interlock relays in ISO Class 5 cleanrooms. Its low electromagnetic emissions prevent interference with sensitive cell culture monitoring equipment—a critical advantage over mechanical relays. Over two years, the site reported zero DO-related deviations during regulatory audits. Similarly, at a Canadian oil sands upgrader, CC-PDOB01 modules have operated continuously in ambient temperatures exceeding 60°C inside non-ventilated panels, demonstrating exceptional thermal resilience and solid-state reliability in abrasive, high-dust conditions.

Related Product Combination Solutions

C300 Controller: Central processing unit—orchestrates all I/O including CC-PDOB01 commands.

CC-TDDI01: 32-channel digital input module—complements CC-PDOB01 for complete discrete control.

FTEB Backplane: Fiber-optic redundant backplane—enables hot-swap and high-availability for CC-PDOB01.

CC-PAIH01: 16-channel analog input module—used alongside CC-PDOB01 in hybrid safety loops.

Safety Manager ST3000: Dedicated safety platform—certifies CC-PDOB01 for SIL2 shutdown sequences.

Experion Studio: Configuration environment—auto-maps CC-PDOB01 tags and enables diagnostic logging.

CC-PSAI01: Analog output module—extends control range when paired with CC-PDOB01 discrete actions.

CC-PSU01: Redundant power supply—ensures stable 24VDC delivery to CC-PDOB01 field circuits.

Installation, Maintenance, and Full-Cycle Support

Installation begins by snapping the CC-PDOB01 into an available slot on a C300 or FTEB rack until it clicks securely. Field wiring connects to removable screw-clamp terminals (0.2–2.5 mm²). Note: an external 24VDC power supply (L+ and M) must be provided for the load circuit—this module does not generate output voltage. Upon power-up, a steady green “OK” LED confirms communication with the controller; a red “Fault” LED indicates overcurrent, overtemperature, or configuration mismatch.

For maintenance, technicians can view real-time channel status via front-panel LEDs or remotely through Experion Operations. If a channel is disabled due to a field fault, resolve the wiring or device issue first—then reset the channel via software or module power cycle. Hot-swap replacement takes under 90 seconds and requires no system reboot when used in redundant configurations. Every CC-PDOB01 we supply undergoes full functional testing, including output accuracy, isolation withstand (500 Vrms), and thermal stress at 70°C.

All units are factory-new, RoHS-compliant, and backed by a 12-month warranty. We provide detailed wiring diagrams, SIL2 validation documentation, and integration support for both standard PKS and Safety Manager deployments.
