Description

The ABB KUC755AE106(Order Code:3BHB005243R0106)is a high-performance controller module from ABB’s AC 800M High Integrity(HI)platform,engineered for safety-critical applications requiring IEC 61508 SIL 3 compliance.It serves as the central processing unit in ABB Ability™System 800xA High Integrity safety systems,designed for demanding sectors such as oil&gas,petrochemicals,power generation,and mining,where functional safety,reliability,and deterministic response are paramount.

Building upon the legacy of the KUC711 series,the KUC755 offers enhanced processing power,larger memory capacity,and improved communication bandwidth,enabling more complex safety logic,faster scan cycles,and seamless integration with modern digital architectures—including support for PROFIsafe over PROFINET and advanced diagnostics via System 800xA Safety Portal.

Application Scenario

At a large-scale LNG liquefaction plant in Australia,engineers needed to upgrade an aging relay-based emergency shutdown(ESD)system to a SIL 3-certified programmable solution capable of managing over 3,000 safety I/O points across multiple process trains.They deployed triplicated(2oo3)KUC755AE106 controllers,each interfacing with:

FS242/FS244 safety analog input modules(for pressure,temperature,level)

FS252/FS254 safety digital output modules(for valve actuators and motor trips)

Fire&gas detection networks via FS212 communication gateways

During a full-plant proof test,the system demonstrated a response time of<80 ms from fault detection to final element actuation—well within the required PFD(Probability of Failure on Demand)targets.The integrated online diagnostics identified a degraded solenoid valve during routine operation,enabling predictive maintenance and avoiding a potential spurious trip.Since commissioning,the system has achieved zero safety incidents and 99.999%availability.

Key Specifications

Parameter Value/Description

Model KUC755AE106

ABB Order Code 3BHB005243R0106

Product Family AC 800M High Integrity(HI)–System 800xA Safety

Safety Certification IEC 61508 SIL 3,IEC 61511,EN 50205 Type B,ATEX,IECEx,cULus

Architecture Supports 1oo2D(single unit,dual diverse channels)or 2oo3(triplicated redundancy)

Processor Dual-core,diverse RISC CPUs with hardware-enforced isolation and cross-checking

Memory

•Safety Application Memory:32 MB Flash(retentive)

•Runtime RAM:64 MB(with ECC and periodic self-test)

Execution Performance

•Boolean instruction:~0.05µs

•Typical safety scan cycle:10–50 ms(configurable based on logic complexity)

Communication Interfaces

•Dual 10/100 Mbps Ethernet ports:

–Safety Network:For I/O,peer sync,and PROFIsafe(via CI874)

–Service/Engineering Port:Secured access for diagnostics and updates

•RS-232(local service interface)

Redundancy&Synchronization

•Optical fiber link(via CI874)for deterministic inter-controller sync(<1 ms jitter)

•Continuous state comparison with automatic fail-safe transition

Supported Protocols

•PROFIsafe over PROFINET(with CI874)

•Modbus TCP Safety(legacy)

•Native AC 800M Safety Bus(for FS2xx I/O)

Programming Environment Control Builder M Safety(IEC 61131-3+safety extensions)

•TÜV-certified function block library(e.g.,S_MOTOR,S_VALVE,S_INTERLOCK)

•Automatic PFD/PFH calculation and documentation

Diagnostics&Cybersecurity

•Built-in web server with role-based access

•Secure boot,firmware signature verification

•Audit trail compliant with ISA-84 and NAMUR NE 43

Power Consumption~15 W

Mounting DIN rail in certified TK872/TK874 cabinets

Operating Temperature 0°C to+60°C(derating above 50°C)

Note:The suffix“AE106”indicates this is a specific firmware/hardware revision optimized for large-scale,high-speed safety applications.Always verify compatibility with your I/O and communication modules.

Technical Advancements Over KUC711

✅4×faster CPU and 4×more memory→supports larger safety applications

✅Native PROFINET/PROFIsafe support(via CI874)→simplifies integration with modern drives and remote I/O

✅Enhanced cybersecurity→meets IEC 62443-3-3 requirements for zone/conduit models

✅Improved diagnostics granularity→pinpoints failing components(e.g.,individual channel in FS252)

Typical Applications

HIPPS(High-Integrity Pressure Protection Systems)

Integrated ESD&F&G(Emergency Shutdown&Fire/Gas)

Burner Management Systems(BMS)in boilers/furnaces

Turbine&compressor overspeed protection

Railway signaling safety interlocks

Offshore platform process safety

Required Companion Modules(Example 2oo3 Setup)

Module Function

CI874 PROFINET/PROFIsafe&optical sync interface

FS242/FS244 Safety analog inputs(4–20 mA,HART)

FS252/FS254 Safety digital outputs(relay or solid-state)

FS212 Gateway for third-party F&G systems

PS874 Redundant 24 VDC power supply(HI-rated)

TK874 Shielded,grounded safety cabinet

Engineering&Lifecycle Best Practices

Design in Control Builder M Safety using certified templates.

Validate safety integrity(PFD,MTTF,DC)automatically via built-in tools.

Perform HIL(Hardware-in-the-Loop)testing before site deployment.

Enable online diagnostics for predictive maintenance.

Archive all safety application versions with digital signatures.

⚠️Critical:Only ABB-certified Safety Engineers may develop or modify logic.Unauthorized changes invalidate SIL certification and void insurance coverage.

Availability&Support Status(2025)

The KUC755AE106(3BHB005243R0106)is actively manufactured and fully supported by ABB as a flagship module in the System 800xA High Integrity portfolio.ABB guarantees:

Production and spare parts until at least 2035+

Regular firmware updates(including cybersecurity patches)

Global service and repair centers

We offer:

New original units with full safety documentation(TÜV certificate,FMEDA report)

Pre-engineered safety applications(e.g.,HIPPS,ESD logic)

On-site commissioning and FAT support

Training for certified safety system engineers

Each unit undergoes:

Burn-in testing(72 hours)

Functional safety validation

Traceability to manufacturing batch

Final Note

The ABB KUC755AE106 represents the convergence of functional safety,cyber resilience,and industrial performance.In an era where operational risk and digital threats are escalating,it provides a trusted foundation for protecting lives,assets,and the environment—without compromising on efficiency or scalability.

Contact us for immediate stock,SIL-compliant engineering services,or migration from legacy safety systems(e.g.,Triconex,Siemens FSC).When safety is non-negotiable,the KUC755AE106 delivers certainty—every millisecond,every day.
