Description:

The TRICONEX 2290614 is a 32-channel,24VDC wetted digital input module engineered for the Tricon®and Triconex®safety instrumented system(SIS)platforms.As a core component of Schneider Electric’s high-integrity control architecture,it delivers fault-tolerant signal acquisition from field devices—such as pushbuttons,limit switches,and relay contacts—in safety-critical applications across oil&gas,chemical,and power generation industries.

Designed to meet IEC 61508 SIL3 and IEC 61511 standards,the 2290614 leverages Triple-Modular Redundancy(TMR)at the channel level to ensure continuous operation even during internal or external faults—making it indispensable for emergency shutdown(ESD),fire&gas(F&G),and burner management systems.

Application Scenarios:

At an offshore drilling platform in the North Sea,a legacy safety system suffered repeated nuisance trips due to ground loops and voltage transients on discrete inputs from mud pump status switches.During a storm-induced brownout,a false“low lube oil pressure”signal triggered an unnecessary wellhead shutdown—costing over$1.2 million in deferred production.The operator replaced the old PLC-based interlocks with a Triconex SIS featuring the TRICONEX 2290614 modules.Each of the 32 channels on the 2290614 operates in full TMR:three independent circuits vote on every input state,rejecting noise-induced glitches while maintaining fail-safe behavior.After deployment,nuisance trips dropped to zero over 24 months,and the system successfully initiated two real ESD events without error.For the platform engineers,the 2290614 became synonymous with“trustworthy silence”—only acting when absolutely necessary.

Main Parameters Value/Description

Product Model 2290614

Manufacturer Schneider Electric(formerly Invensys,Triconex)

Product Category 32-Channel Digital Input Module(TMR,Wetted)

Input Type 24VDC wetted(sourcing);compatible with dry contacts via external wetting

Number of Channels 32(grouped in 4 banks of 8)

Voltage Range 18–30 VDC(nominal 24 VDC)

Input Current~2.5 mA per channel(with wetting)

Isolation Channel-to-channel and channel-to-backplane(500 Vrms min)

Redundancy Architecture Triple-Modular Redundancy(TMR)per channel

Diagnostic Coverage>99%(per IEC 61508)

Hot-Swap Support Yes—module can be replaced during system operation

Operating Temperature 0°C to+60°C(extended range options available)

Certifications IEC 61508 SIL3,IEC 61511,ATEX,UL,CSA,FM,TÜV Rheinland

Technical Principles and Innovative Values:

Innovation Point 1:Per-Channel TMR Voting–Unlike conventional redundant I/O that duplicates entire cards,the 2290614 implements three independent sensing circuits per input channel.All three readings are voted in real time by the Tricon main processors;only a 2-out-of-3 agreement is accepted.This eliminates single-point failures and rejects transient noise that might fool a single sensor.

Innovation Point 2:Wetted Input with Built-In Diagnostics–The 2290614 supplies 24VDC directly to field contacts(“wetted”),enabling detection of open wires,short circuits,and degraded switch contacts through current monitoring—critical for proving loop integrity in safety applications.

Innovation Point 3:Zero Configuration,Full Transparency–Once installed in a Tricon chassis,the 2290614 auto-enumerates in the TriStation 1131 engineering suite.No DIP switches,jumpers,or software channel mapping are needed—reducing commissioning errors and speeding up FAT.

Innovation Point 4:Fail-Safe Default Behavior–On loss of power,communication,or internal fault,every channel defaults to a safe state(typically“0”or de-energized),ensuring the SIS remains in a known protective condition—never ambiguous.

Application Cases and Industry Value:

In a hydrogen reformer unit at a U.S.Gulf Coast refinery,the existing F&G system used non-redundant DI cards that failed to detect a slow-closing isolation valve during a leak test.The incident led to a Tier II EPA reportable event.Post-audit,the site upgraded to a Triconex SIS with TRICONEX 2290614 modules handling all flame detector,gas sensor,and valve position feedback signals.During a subsequent hydrogen leak simulation,the 2290614 correctly identified a stuck valve within 80 ms and triggered a full unit depressurization.Auditors later cited the module’s diagnostic coverage and TMR architecture as key factors in the system’s flawless response.Plant safety managers now refer to the 2290614 as their“digital conscience”—always watching,never fatigued.

Related Product Combination Solutions:

TRICONEX 3503E–Main processor module for Tricon v10/v11 systems that interfaces with 2290614

TRICONEX 3700A–Chassis backplane supporting hot-swap and TMR synchronization for 2290614

TRICONEX 3624–16-channel analog output module for actuator control in tandem with DI logic

TRICONEX 3511–Communication module for Modbus or Ethernet/IP integration with DCS

TRICONEX 2290624–32-channel dry contact version(non-wetted)for passive switch inputs

TRICONEX 3301E–Power supply module with redundancy support for the entire Tricon rack

TriStation 1131–Engineering software used to configure,test,and diagnose 2290614 channels

TRICONEX 3955E–Remote I/O terminal for distributed 2290614-style inputs in large plants

Installation,Maintenance,and Full-Cycle Support:

The TRICONEX 2290614 installs into any compatible Tricon chassis(e.g.,3700A)and requires no configuration—field wiring connects directly to its front-terminal block(screw-clamp type).Ensure 24VDC wetting power is stable and filtered;use shielded,twisted-pair cables with single-point grounding to minimize EMI.The module supports hot-swap:simply unlock the front handle,remove the unit,and insert a replacement—the Tricon system maintains operation using the last valid voted state until the new module synchronizes(typically<2 seconds).

Maintenance is largely predictive:the Tricon system continuously monitors each channel for opens,shorts,and voting mismatches,logging faults in the event history.No calibration is required.In the rare event of failure,the 2290614’s modular design allows replacement in under 5 minutes.

We provide only genuine,factory-new or Schneider-certified refurbished 2290614 units,each tested on live Tricon hardware for TMR voting accuracy,wetting voltage stability,hot-swap behavior,and diagnostic reporting.Every module includes a full functional test report,12-month warranty,and compatibility verification with your Tricon firmware version.Our certified Triconex engineers offer 24/7 technical support—from spare validation to emergency troubleshooting.

Contact us for a customized solution—whether you’re expanding a safety system,replacing obsolete I/O,or securing long-term spares for your Triconex SIS.With deep expertise in high-integrity automation,we ensure your safety logic remains uncompromised,compliant,and always ready to act.
