Product Description

Description:

The ABB 216AB61​is an essential cooling fan assembly designed for ABB’s Bailey INFI 90 distributed control system(DCS).This critical thermal management component ensures optimal operating temperatures for sensitive electronic modules within INFI 90 racks and cabinets.It is engineered to provide reliable forced-air cooling,protecting valuable control system components from heat-related damage and premature failure.

Application Scenarios:

In a coal-fired power plant’s control room,the Bailey INFI 90 DCS operates 24/7 to manage boiler controls,turbine sequencing,and burner management.The electronic modules in these systems generate significant heat,and without proper cooling,their performance degrades,leading to measurement drift,processor faults,or complete system failure.The ABB 216AB61​fan assembly operates continuously,drawing cool air across the densely packed processor,communication,and I/O modules.A real-world case involved a Midwest utility that experienced repeated processor resets during summer peaks.Investigation revealed that several original fan assemblies had failed,causing overtemperature conditions.Replacing them with genuine 216AB61​units restored proper airflow,eliminated the resets,and prevented potential thousands of dollars in module damage and unplanned outage time,highlighting its role in ensuring system availability.

Parameter:

Main Parameters

Value/Description

Product Model​

216AB61​

Manufacturer​

ABB(formerly Bailey Controls)

Product Type​

Fan Assembly/Cooling Unit

Compatible System​

Bailey INFI 90 Distributed Control System

Voltage Rating​

120V AC(Common for US installations)

Airflow Capacity​

High-CFM designed for full rack cooling

Mounting​

Slides into dedicated slots in INFI 90 chassis

Connection​

Modular power connector

Status Indication​

May include rotation sensing or fault monitoring

Material​

Metal chassis with blade grill for safety

Operational Life​

Designed for continuous duty operation

Technical Principles and Innovative Values:

The ABB 216AB61,while mechanically simpler than a processor module,embodies a critical,reliability-focused design philosophy for industrial DCS environments.

Innovation Point 1:System-Integrated Thermal Management.​Unlike generic fans,the 216AB61​is engineered specifically for the airflow dynamics and heat load of a populated INFI 90 chassis.Its form factor,mounting,and airflow path are optimized to target hot spots on key modules like the NPRL61​Multi-Function Processor,ensuring heat is efficiently expelled from the enclosure to maintain all components within their specified temperature ranges,which is fundamental for long-term stability and accuracy.

Innovation Point 2:Focus on Mean Time Between Failures(MTBF).​In a DCS,a single point of failure can be catastrophic.The 216AB61​uses industrial-grade ball-bearing motors designed for high MTBF,offering superior longevity and reliability compared to consumer-grade fan units.This focus on component-level robustness is a key innovation that directly translates to reduced maintenance frequency and higher overall system availability.

Innovation Point 3:Simplified Serviceability.​The assembly is designed as a field-replaceable unit(FRU).It can typically be swapped out without tools or without needing to de-energize the entire rack,thanks to its slide-in design and dedicated connector.This design for maintenance minimizes system downtime during replacement,a crucial factor for continuous process industries.

Application Cases and Industry Value:

Case 1:Pulp and Paper Mill DCS Reliability Upgrade.​A large pulp mill in Scandinavia operating a legacy Bailey INFI 90 system began experiencing intermittent communication errors on its NFCL61​Communication Module.Diagnostic logs pointed to occasional overtemperature warnings.An inspection found that the original fan assemblies,including several 216AB61​units,were operating at reduced speed due to bearing wear.Replacing all aging fans with new ABB 216AB61​assemblies resolved the communication errors.This proactive maintenance prevented a potential breakdown in the paper machine control system,which would have cost an estimated$50,000 per hour in lost production.

Case 2:Chemical Plant Legacy System Support.​A chemical processing facility chose to extend the life of its proven Bailey INFI 90 system rather than undertake a costly full system migration.A key part of their lifecycle management plan was the systematic replacement of all mechanical wear items,with cooling fans being a top priority.They standardized on the 216AB61​as the approved replacement,stocking units to ensure quick change-out during planned outages.This strategy has successfully extended the system’s operational life by over a decade,deferring major capital expenditure while maintaining high reliability.

Related Product Combination Solutions:

The ABB 216AB61​is a component of a larger system.Key related products include:

ABB 216AB61​(Fan Assembly):​The core cooling unit.

ABB NPRL61​Multi-Function Processor:​A primary heat-generating component cooled by the fan.

ABB NFCL61​Communication Module:​A critical module that relies on stable temperature for proper network operation.

ABB CMI61​Chassis/Module Interconnect:​The main rack that houses the modules and fan assemblies.

ABB 216EA61​Power Supply:​The unit that provides power to the fan assemblies and modules.

ABB 216FB61​I/O Module Example:​Representative of the many I/O modules that require cooling.

Installation,Maintenance,and Full-Cycle Support:

Installation of the ABB 216AB61​is a straightforward process designed for minimal downtime.For planned maintenance,the technician would first,if possible,place the specific chassis or related control logic in a safe state.The old fan assembly is simply de-energized,unplugged,and slid out of its guides.The new 216AB61​unit is then aligned with the guides,slid completely into place until it seats firmly,and the power connector is engaged.Finally,verification of operation involves confirming that the fan starts and runs smoothly,and that any system diagnostics recognize the unit as operational.

Routine maintenance should include periodic visual inspections for dust accumulation and listening for abnormal bearing noise,which can be an early indicator of impending failure.Proactive replacement based on service life(often recommended every 5-7 years for continuous duty)is more cost-effective than waiting for a failure that could lead to module damage.We source our 216AB61​fan assemblies from certified channels to ensure they meet original specifications.Each unit undergoes a functional test prior to shipment to verify operation.We provide a 12-month warranty and technical support to assist with integration into your specific INFI 90 chassis configuration.
