Product Overview

The ABB CI871AK01 3BSE092693R1​is a high-performance PROFIBUS DP communication interface module manufactured by ABB,designed for industrial automation and process control systems.This advanced communication module serves as a crucial gateway between ABB’s control systems and PROFIBUS DP field networks,enabling seamless data exchange with various field devices.The ABB CI871AK01 3BSE092693R1​provides reliable,real-time communication capabilities for industrial applications where robust network connectivity and device integration are essential for operational efficiency.

As part of ABB’s industrial automation portfolio,the ABB CI871AK01 3BSE092693R1​supports both DP-V0 and DP-V1 PROFIBUS protocols,ensuring compatibility with a wide range of field devices including drives,I/O systems,and measuring equipment.The module’s rugged industrial design ensures reliable operation in demanding environments,with an operating temperature range of 0°C to+60°C.The ABB CI871AK01 3BSE092693R1​features comprehensive diagnostic capabilities that monitor network health and device status,enabling proactive maintenance and minimizing system downtime.With its flexible configuration options and easy integration,this communication interface represents a reliable solution for modern industrial networking requirements.

Technical Specifications

Product Model|ABB CI871AK01 3BSE092693R1

Manufacturer|ABB

Product Type|PROFIBUS DP Communication Interface

Communication Protocol|PROFIBUS DP(DP-V0,DP-V1)

Data Transfer Rate|9.6 Kbps to 12 Mbps

Interface|RS-485,9-pin D-sub connector

Isolation|1500V AC

Power Supply|24V DC via baseplate

Power Consumption|5W maximum

Operating Temperature|0°C to+60°C

Storage Temperature|-40°C to+85°C

Relative Humidity|5%to 95%non-condensing

MTBF|>100,000 hours

Certifications|CE,UL,cULus

Dimensions|200mm×120mm×80mm

Main Features and Advantages

The ABB CI871AK01 3BSE092693R1​incorporates advanced communication technology that ensures reliable data exchange in industrial environments.The module supports cyclic and acyclic data communication,enabling both process data exchange and parameter configuration with field devices.Its integrated diagnostics provide comprehensive network monitoring,including bus error statistics,device status information,and signal quality indicators.The module’s automatic baud rate detection simplifies commissioning,while the configurable watchdog timer ensures system responsiveness.

Network reliability and performance:Featuring galvanic isolation of 1500V AC,the ABB CI871AK01 3BSE092693R1​protects the control system from electrical disturbances on the fieldbus.The module supports up to 244 bytes of input data and 244 bytes of output data,accommodating complex automation requirements.In manufacturing applications,this capability enables seamless integration of multiple drives and I/O points on a single network segment,significantly reducing wiring complexity and installation costs.

Configuration and diagnostics:The ABB CI871AK01 3BSE092693R1​is configured using ABB’s engineering tools,with simple parameter setting for network configuration and device mapping.Comprehensive diagnostic information is available through LED indicators and software tools,facilitating quick troubleshooting and reducing mean time to repair.The module’s non-volatile memory retains configuration parameters during power cycles,ensuring rapid system recovery after outages.

Technical Overview:

The ABB CI871AK01 3BSE092693R1 represents advanced fieldbus communication technology with proven reliability in industrial environments.Its PROFIBUS DP interface supports high-speed data exchange up to 12 Mbps,ensuring real-time communication with field devices.The module’s robust construction and comprehensive diagnostic capabilities make it suitable for demanding industrial applications.Advanced features include automatic baud rate detection,configurable watchdog timer,and non-volatile memory for parameter retention.The module’s design ensures reliable operation in harsh industrial conditions while maintaining easy integration with ABB’s control systems.

Application Field

The ABB CI871AK01 3BSE092693R1​finds extensive application across various industrial sectors requiring robust fieldbus communication.In manufacturing automation,the module enables integration of distributed I/O systems,motor starters,and variable frequency drives into unified control architectures.The high-speed data exchange capability supports real-time control requirements for automated assembly lines and material handling systems.

In process industries,the ABB CI871AK01 3BSE092693R1​facilitates communication with measuring devices,actuators,and analytical instruments,supporting precise process control and monitoring.The module’s reliability makes it suitable for critical applications in chemical processing,water treatment,and pharmaceutical manufacturing.Additional applications include:

Automotive manufacturing lines

Food and beverage processing

Pharmaceutical production systems

Water and wastewater treatment

Power generation facilities

Oil and gas processing plants

Related Products

ABB CI858​-Ethernet communication interface

ABB CI867​-PROFINET IO controller

ABB CI869​-Foundation Fieldbus interface

ABB CI871​-PROFIBUS DP master module

ABB TU847​-Termination unit

ABB CP642​-Control processor

ABB DS200​-I/O modules

ABB IS200​-Signal conditioning modules

Installation and Maintenance

Installation requirements:The ABB CI871AK01 3BSE092693R1​requires proper mounting in the control rack with secure connection to the baseplate.PROFIBUS network installation must follow guidelines for cable selection,termination,and grounding.Use shielded twisted-pair cables with proper bus termination at both ends of the network segment.The module requires 24V DC power supplied through the baseplate connection.

Maintenance recommendations:Regular maintenance includes monitoring network diagnostics,checking cable integrity,and verifying connector tightness.The ABB CI871AK01 3BSE092693R1’s diagnostic functions should be periodically reviewed to identify potential network issues.Firmware updates should be applied during planned maintenance windows following manufacturer recommendations.Network performance should be verified using PROFIBUS diagnostic tools to ensure signal quality and communication reliability.

Product Guarantee

We guarantee that all ABB CI871AK01 3BSE092693R1​modules are genuine ABB products,manufactured to original specifications and subjected to comprehensive testing.Our quality assurance process includes verification of communication functions,protocol compliance,and electrical characteristics.We provide complete technical documentation and configuration support to ensure successful integration into your automation system.All modules are covered by our standard warranty with technical support available for configuration and troubleshooting.Our inventory management maintains adequate stock levels to support both new projects and maintenance requirements,with expedited shipping options for urgent needs.

Product Lifecycle and Service Commitment:

The ABB CI871AK01 3BSE092693R1 is a current product in ABB’s portfolio with full technical support.We ensure genuine components with complete documentation and testing certification.Our global supply chain guarantees availability for both new installations and maintenance requirements.We provide comprehensive technical support and warranty coverage to ensure optimal performance throughout the product lifecycle.
