Description

The ABB INNIS21​is a 16-channel digital input(DI)module manufactured by ABB,forming a critical component of the Advant Open Control System(OCS)and MOD 300 families.This module serves as the fundamental interface between the control system and field-mounted binary devices,converting real-world on/off signals from the plant floor into digital data for the controller.It is engineered for high-density,reliable signal acquisition in critical process automation and safety applications.

Application Scenarios

In a chemical processing plant,monitoring the state of hundreds of motor-operated valves—whether they are fully open or fully closed—is critical for batch sequencing and safety interlocks.A single faulty input reading could lead to an incorrect sequence,a failed batch,or a hazardous condition.The ABB INNIS21​is deployed in distributed I/O panels throughout the plant,providing a robust and reliable interface for these limit switches.Its high channel density allows for monitoring 16 valves with a single module,reducing cabinet footprint and wiring complexity,while its high signal integrity ensures the control system always has an accurate picture of the process state,preventing costly operational errors and enhancing overall plant safety.

Parameter

Main Parameters

Value/Description

Product Model

ABB INNIS21​

Manufacturer

ABB Ltd.

Product Category

Digital Input Module(DI)

Parent System

Advant OCS,MOD 300,S800 I/O

Number of Channels

16(Grouped in 8)

Input Voltage Range

24 VDC(Nominal)

Logic”1″Level

13-30 VDC

Logic”0″Level

0-5 VDC

Input Current

Typically 6 mA per point

Electrical Isolation

500 V AC between field,system,and channel groups

Module Mounting

S800 I/O Station(e.g.,ABB SA801​baseplate)

Diagnostic Features

Channel group fuse failure indication

Key Function

Interfaces field contact signals(e.g.,limit switches,pushbuttons)to the controller

Technical Principles and Innovative Values

The ABB INNIS21​is designed with a focus on reliability,safety,and ease of maintenance in industrial environments.

Innovation Point 1:Grouped Channel Isolation and Diagnostics.​The 16 channels on the ABB INNIS21​are organized into two groups of eight,with optical isolation between the field side and the system side.This design prevents faults in one field device from propagating and taking down the entire module.A dedicated fuse for each group,with a central diagnostic signal,allows for rapid identification of a field wiring short circuit,drastically reducing troubleshooting time.

Innovation Point 2:High Noise Immunity.​The module is engineered to operate reliably in electrically noisy industrial environments.Its robust input circuit design provides excellent immunity against electromagnetic interference(EMI)and transients,ensuring that the digital signals read by the controller are a true representation of the field device state,eliminating false trips and erroneous readings.

Innovation Point 3:Seamless System Integration.​As a native component of the ABB Advant and MOD 300 systems,the ABB INNIS21​is automatically recognized and configured by the master controller(e.g.,ABB AC 410).This plug-and-play functionality,combined with a standardized mechanical form factor,simplifies spare part stocking,module replacement,and system expansion.

Application Cases and Industry Value

Case 1:Pulp and Paper Mill Stock Preparation

A pulp mill utilized the ABB INNIS21​modules across its distributed control system to monitor the position of numerous pulp stock valves and the status of pump seals.The high channel count of the ABB INNIS21​minimized the number of I/O modules required,reducing both hardware costs and cabinet space.The modules’robust performance in a humid,corrosive,and electrically noisy environment was critical.Their reliable operation over more than a decade ensured accurate process sequencing and contributed to the mill’s record of continuous,uninterrupted operation,with maintenance only required during planned shutdowns.

Case 2:Power Plant Turbine Bypass System

In a combined-cycle power plant,the turbine bypass system requires extremely reliable monitoring of valve positions for safe operation.The ABB INNIS21​modules were chosen for this application due to their proven track record and built-in diagnostic capabilities.The group fuse failure indication allowed plant electricians to quickly identify and isolate a wiring fault during a commissioning test,preventing a potential system shutdown and demonstrating the module’s value in maintaining high availability in critical systems.

Related Product Combination Solutions

ABB INNIS22:The digital output(DO)counterpart to the ABB INNIS21,used to command field actuators like solenoid valves and motor starters from the same control system.

ABB AI810:An 8-channel analog input module,used in the same S800 station as the ABB INNIS21​to handle continuous process signals like pressure and temperature.

ABB SA801:The standard S800 I/O station baseplate that provides the physical mounting,power,and data bus for the ABB INNIS21​and other I/O modules.

ABB AC 410:The Advant Controller that acts as the master,scanning and processing the input data from all the ABB INNIS21​modules in the system.

ABB CI522:A communication interface module that connects the S800 I/O station,housing the ABB INNIS21,to the higher-level control network.

ABB SD821:The power supply for the S800 I/O station,providing the internal logic power required for the ABB INNIS21​to operate.

Installation,Maintenance,and Full-Cycle Support

Installing the ABB INNIS21​is a streamlined process.The module is designed to plug securely into its designated slot on an S800 I/O station baseplate like the SA801.The field wiring is connected to the removable front terminal block,with clear markings for each channel and the associated common power connections for each group.Proper grounding and the use of shielded cables for long runs are recommended to ensure optimal noise immunity.

Routine maintenance for the ABB INNIS21​is minimal,primarily involving periodic visual inspections and checking that the station ventilation is not obstructed.The most common maintenance activity is responding to a group fuse failure indication.This diagnostic feature immediately alerts the operator to a short circuit in a specific group of 8 channels,allowing for rapid isolation and repair without affecting the other 8 channels on the module.Module replacement is a simple hot-swap procedure in redundant systems,ensuring no process interruption.

We provide comprehensive full-cycle support for the ABB INNIS21,from initial system configuration and spare part provisioning to technical troubleshooting.Our commitment includes supplying 100%genuine,factory-tested modules with full traceability.We ensure you have access to the necessary technical documentation and firmware to maintain your system’s integrity and performance over its entire operational lifecycle.

Contact us for a customized solution and to ensure the ABB INNIS21​is optimally configured for your specific application needs.
