Description

The ABB GFD563A102 3BHE046836R0102​represents a high-performance feeder protection relay within ABB’s Relion®650 series,designed for comprehensive protection and control of electrical distribution systems.This advanced Intelligent Electronic Device(IED)provides reliable overcurrent,earth fault,and directional protection functions for medium-voltage feeders.Engineered for industrial and utility applications,the GFD563A102 3BHE046836R0102​ensures electrical system security through fast,selective fault clearance and advanced monitoring capabilities.

Application Scenarios

In a large industrial facility in Germany,the ABB GFD563A102 3BHE046836R0102​was deployed to protect critical 6kV distribution feeders supplying production equipment.The previous electromechanical relays suffered from slow response times and lacked coordination capabilities,causing widespread outages during feeder faults.After implementing the GFD563A102 3BHE046836R0102,the facility achieved selective fault clearance within 20 milliseconds,reduced outage scope by 80%,and improved system availability to 99.98%.The chief electrical engineer reported:”The GFD563A102 3BHE046836R0102’s precise coordination and fast operation have been crucial for maintaining our production continuity while ensuring electrical safety.”

Parameter

Main Parameters

Value/Description

Product Model

ABB GFD563A102 3BHE046836R0102​

Manufacturer

ABB Switzerland Ltd

Product Category

Feeder Protection Relay

Product Series

Relion®650 Series

Rated Voltage

6-36kV AC

Frequency

50/60 Hz

Protection Functions

Overcurrent(50/51),Earth Fault(50N/51N),Directional Overcurrent(67/67N)

Measuring Elements

3-phase current,1 earth fault current

Communication Ports

2x Ethernet,2x RS485,1x USB

Protocols

IEC 61850,Modbus TCP,DNP3.0

Operation Temperature

-40°C to+70°C

Display

5.7″LCD with touch interface

Fault Records

1000 events with oscillography

Binary Inputs

24 programmable

Binary Outputs

18 programmable

Certifications

IEC 60255,IEEE C37.90,UL 1054

Technical Principles and Innovative Values

Advanced Protection Algorithms:The ABB GFD563A102 3BHE046836R0102​utilizes numerical algorithms with full-cycle Fourier transform for accurate current measurement and fault detection.The relay’s directional overcurrent protection employs voltage polarization to ensure correct fault direction identification,while the multi-shot autoreclosing function enhances service restoration for transient faults.This sophisticated approach enables selective coordination with downstream protective devices,minimizing outage impact.

Intelligent System Integration:Featuring native IEC 61850 station bus communication,the relay seamlessly integrates into digital substation architectures.The GFD563A102 3BHE046836R0102’s GOOSE messaging capability enables fast protection coordination between devices,while the comprehensive event recording and disturbance analysis functions provide valuable data for post-fault analysis and system optimization.

Robust Environmental Performance:Designed for harsh industrial environments,the relay operates reliably across a wide temperature range with high immunity to electromagnetic interference.The ABB GFD563A102 3BHE046836R0102’s reinforced insulation and robust construction ensure long-term reliability in demanding applications,with an MTBF exceeding 250,000 hours.

Application Cases and Industry Value

Case Study:Commercial Building Distribution System Upgrade

A large commercial complex in Singapore selected the ABB GFD563A102 3BHE046836R0102​for their medium-voltage distribution system modernization.The existing protection system lacked coordination,causing entire building sections to lose power during localized faults.After implementing the GFD563A102 3BHE046836R0102​with coordinated protection settings,the facility achieved zone-selective interlocking,reduced outage scope by 90%,and maintained critical services during faults.The facilities manager confirmed:”The GFD563A102 3BHE046836R0102’s selective protection has been instrumental in maintaining our tenant services while significantly improving our electrical system reliability.”

Related Product Combination Solutions

ABB GFD563A101​-Basic feeder protection version

ABB GFD563A103​-Enhanced communication version

ABB RET615​-Transformer protection relay

ABB REF615​-Feeder protection with enhanced features

ABB REC615​-Capacitor bank protection

ABB REG615​-Generator protection

ABB REQ615​-Motor protection

Installation,Maintenance,and Full-Cycle Support

Installation and Commissioning:The ABB GFD563A102 3BHE046836R0102​features a compact design for panel mounting with clear terminal markings.Pre-commissioning requires CT/PT ratio verification and protection setting calculations using ABB’s PCM600 software.The relay’s auto-configuration capability and test mode facilitate commissioning without system disruption.

Maintenance and Technical Support:Regular maintenance includes annual protection characteristic verification and firmware updates.The GFD563A102 3BHE046836R0102’s comprehensive self-monitoring system provides early warning of potential issues.Our technical support team offers remote diagnostics and setting adjustments.

Lifecycle Management and Service Commitment:ABB provides long-term support for the GFD563A102 3BHE046836R0102​with guaranteed spare parts availability.Our service includes coordination studies and migration services for legacy systems.

Contact us today for a comprehensive protection solution assessment and discover how the ABB GFD563A102 3BHE046836R0102​can enhance your system reliability while providing advanced protection and control capabilities.
