DEIF GPU 2 GS Digital Protection Relay for Grid Synchronization and Safety Protection

Product Overview and Technical Features

The DEIF GPU 2 GS digital protection relay is a high-performance control device designed specifically for generator synchronization and grid safety protection. As a key member of DEIF’s RMC series of protection relays, it utilizes advanced digital signal processing technology to accurately monitor grid parameters and provide reliable protection.

Core Features:

Differential Current Protection: Compares the differential current of each of the three phases to provide RMS sinusoidal current measurement. Peak-based measurement ensures short response times during faults.

Flexible Parameter Configuration: Users can select different parameter settings to suit a variety of application scenarios.

Synchronous Control: Automatically initiates generator ordering when voltage, frequency, and phase angle differences are detected within preset limits.

Dynamic Synchronous Control: Prevents reverse power conditions under differential frequency, ensuring stable power system operation.

Technical Specifications and Performance

The DEIF GPU 2 GS digital protection relay offers the following technical features:

Parameter Category Technical Specifications

Differential current setpoint adjustable from 100% to 400%

Response time <50 milliseconds

Contact configuration: Two sets of parallel contacts

Measurement accuracy: High-precision RMS measurement

Operating environment: Suitable for industrial temperature range

This product features a modular design that supports a variety of protection function combinations, including short-circuit protection, overcurrent protection, and ground fault protection. Its compact design allows for easy integration into various power control systems.

Grid Synchronization Application Cases

The DEIF GPU 2 GS excels in grid synchronization and has been widely used in various fields:

Generator Grid Connection Control: In a large hydropower project, the DEIF GPU 2 GS successfully achieved precise synchronization of multiple generators, reducing grid connection time by 40% and significantly improving system stability.

Microgrid Operation: In off-grid microgrid systems, the relay ensures seamless switchover between distributed power sources and the main grid through dynamic synchronization control.

Industrial Emergency Power Supply: Provides fast synchronization for critical industrial facilities, enabling millisecond-level switchover in the event of a main power failure.

Grid Security Protection Practices

In terms of grid security protection, the DEIF GPU 2 GS ensures system safety through the following mechanisms:

Fast Fault Detection: Peak measurement-based differential protection identifies and isolates faults within 50 milliseconds.

Multi-Level Protection Strategy: Provides multi-level protection from short-circuit protection to ground current protection.

Adaptive Protection Algorithm: Automatically adjusts protection parameters based on grid operating conditions to improve protection accuracy.

An application case at a power company demonstrates that the DEIF GPU 2 GS can effectively protect the system from faults. After implementing the GS, system fault isolation time was reduced from 200 milliseconds to 50 milliseconds, significantly reducing the risk of equipment damage.

Industry Evaluation and Development Trends

Expert Comments:

“The DEIF GPU 2 GS perfectly combines differential protection and synchronous control, providing a comprehensive solution for modern power grids.” – A power system expert

“Its fast response time and high-precision measurement make it an ideal choice for protecting renewable energy grid integration.” – A technical director at a power grid company

Technical Development Trends:

Intelligent: Integrated AI algorithms enable fault prediction and self-healing control.

High Integration: Integrates protection, monitoring, and control functions into a single device.

New Energy Adaptability: Optimizes protection strategies for intermittent power sources such as wind power and photovoltaics.

Communication Capabilities: Supports standard protocols such as IEC 61850, enabling efficient communication between devices.

As the global power system transitions to renewable energy, digital protection relays are becoming smarter, faster, and more reliable. With its superior performance and flexibility, the DEIF GPU 2 GS will play an even more important role in future power grid protection.
