I.Product Overview

Model:11901 APPLIED MATERIALS Radisys PCB

This module is a high-performance embedded printed circuit board(PCB)module jointly developed by Applied Materials and Radisys Corporation(now ADTRAN).It is usually used in semiconductor manufacturing equipment,industrial control systems,automated test platforms or telecommunications-grade communication equipment.

Although”11901″itself may not be a standard Radisys model number,it is likely to be an internal number or custom package module used in Applied Materials devices,and its core hardware comes from Radisys’ENDURA or ISBC series embedded platforms.Therefore,this module has high reliability,wide temperature adaptability and rich I/O interface,which is suitable for industrial field and telecommunications environments with high stability requirements.

II.Basic information speculation(based on industry applications)

Parameter description

MODULE NO.11901 APPLIED MATERIALS

Core manufacturer Radisys Corporation(now ADTRAN)

Application:Semiconductor manufacturing equipment,industrial control,communication system,edge computing

Type Embedded motherboard/industrial control module/communication processing unit

The architecture supports Intel x86 processor architectures(such as Core i7,Xeon E5,etc.)

Compatible with standard ATCA/CompactPCI/custom backplane interface

III.Technical characteristics and functional analysis

1.Processor and memory configuration(typical)

Processor:

Intel®Xeon®E5 or CoreTM i7 series

Support multi-threaded concurrent processing,suitable for complex data acquisition,image recognition or communication protocol stack processing.

Chipset:

Intel®C600 series or later embedded chipset

Memory support:

DDR3/DDR4 ECC memory slot with error correction function

Maximum capacity up to 32GB or more(depending on the version)

2.Storage and scalability

Storage interface:

Onboard CFast or M.2 SSD slots(for system boot)

SATA interface supports high-speed solid-state drives or mechanical hard disks.

Extended interface:

PCIe x4/x8/x16 slot(network cards,encryption cards,FPGA acceleration cards,etc.can be added)

Mini-PCIe slot(often used for wireless modules or small storage extensions)

3.Network interface and communication capacity

Ethernet port:

It integrates multiple Gigabit Ethernet interfaces(GE),and some versions support SFP optical fiber modules.

Configurable to 10GbE module(through PCI Express card)

Management interface:

IPMI 2.0 out-of-band management interface

Provide serial port debugging interface and BMC remote management channel

Support remote switching,log viewing,firmware upgrade and other functions

4.Operating system and virtualization support

Compatible operating system:

Carrier Grade Linux(CGL)

Wind River VxWorks

Red Hat Enterprise Linux(RHEL)

Ubuntu Server LTS

Windows Embedded Standard

Virtualization support:

Support mainstream virtualization platforms such as KVM,Xen,VMware ESXi

Support Docker container environment,adapt to CNF(Cloud Native Network Functions)

IV.Physical characteristics and environmental adaptability

Dimensions:customized according to the needs of the device,which may be ATX,Mini-ITX or standard embedded structures.

Installation method:standard server chassis installation or industrial control cabinet integration

Operating temperature range:-20°C to+70°C(suitable for industrial and data center environments)

Protection level:IP20(recommended for use in a closed environment)

V.Typical application scenarios

1.Semiconductor manufacturing equipment control unit

As a key control component of Applied Materials semiconductor manufacturing equipment,it is responsible for equipment condition monitoring,process parameter adjustment,data acquisition and feedback control.

2.Industrial automation and remote monitoring platform

It is widely used in power,transportation,energy and other fields,and a remote monitoring and control system is built to support the centralized management and fault early warning of distributed stations.

3.Telecom-grade core network element deployment(EPC/IMS/5GC)

It can be used to deploy S-CSCF,P-CSCF,MGCF and other nodes in the IMS architecture,or PGW and SGW components in LTE EPC.

4.Edge computing and CDN nodes

As the core module of the edge server,it can be deployed in CDN cache nodes,AI reasoning platforms or local data centers to achieve low-latency data processing and content distribution.
