The following is a comprehensive analysis and technical interpretation of the three module models 129-0202,60-0368-00 and 61-0511-30 of Radisys Corporation.These modules are usually used in industrial automation,telecommunications equipment,embedded systems and NFV(network function virtualization)platforms,with high reliability,strong compatibility and good scalability.

I.Product Overview

Module Model Type Speculation Application Field

129-0202 may be a backplane/chesis component or communication interface module system integration,module interconnection

60-0368-00 may be a control motherboard or embedded processing module,industrial control,communication master control unit

61-0511-30 may be a storage module or solid-state drive(SSD)system boot disk,data cache

These three are often used as key hardware components of the Radisys ENDURA platform or other embedded systems,forming a complete computing,storage and communication subsystem.

II.Detailed analysis of each module

1.Radisys 129-0202

Type speculation:

Backplate module/system bottom plate/connector module

Function description:

Provide multiple slots for inserting ATCA,CompactPCI or custom modules

Realize high-speed communication and power distribution between modules

Support redundant design to ensure system high availability(HA)

Common application scenarios:

The core structure of telecommunications-grade server chassis

Central connection hub of multi-module system

Physical support framework for high-density communication platform

Features:

Wide temperature working range(-20°C to+70°C)

Support hot-swappable

Compatible with a variety of Radisys modules

2.Radisys 60-0368-00

Type speculation:

Embedded motherboard/control processor module

Function description:

As the main control unit of the system,run the operating system and execute the communication protocol stack(such as SIP,Diameter,GTP,etc.)

Support virtualization platform deployment(KVM,Xen,VMware ESXi)

Provide local storage interfaces(SATA,CFast),Gigabit Ethernet ports,etc.

Common application scenarios:

IMS core network element(such as S-CSCF,P-CSCF)

LTE EPC components(such as PGW,SGW)

Virtualized network function(VNF)node

Technical advantages:

Multi-core Intel x86 architecture processor support

ECC memory protection mechanism

IPMI remote management function

Support Carrier Grade Linux(CGL)

3.Radisys 61-0511-30

Type speculation:

Embedded Solid State Storage Module/CompactFlash Card/CFast Storage Unit

Function description:

It is used for system startup,configuration file storage,logging and other functions.

It can be used as the operating system mirror storage media of VNF nodes.

Support long-term stable operation in low-power consumption and wide-temperature environment

Common application scenarios:

The main guide disk of the embedded system

Industrial control system configuration and storage

NFV node temporary cache

Features:

No mechanical movable parts,shock resistance and high temperature resistance

Support ECC data verification(some versions)

Fast read and write response,suitable for frequent access scenarios

III.Typical system integration examples

In actual deployment,these three modules may be integrated into a Radisys ENDURA series communication platform,such as:

Module Functional Role

129-0202 main back plate,providing slots and power supply

60-0368-00 Master control module,running VNF virtualization instance

61-0511-30 System boot disk,save OS and configuration information

This combination can be applied to the following scenarios:

IMS Session Boundary Controller(SBC)

LTE EPC access gateway

Edge Computing Node(MEC)

Industrial remote monitoring and control system
