DANAHER MOTION 522P35UDRL3000 Product Introduction

Product Overview:

DANAHER MOTION 522P35UDRL3000 is a high rigidity linear motor designed specifically for precision machining, semiconductor manufacturing, and high-speed automation equipment. This product adopts a coreless coil and high-precision magnetic circuit design, supporting nanometer level positioning and high-speed dynamic response. It is suitable for scenarios such as wafer cutting, laser microfabrication, and precision inspection that require strict precision and stability in linear motion. Its compact structure and low thermal deformation characteristics make it an ideal choice for high-density equipment integration, while being compatible with multi protocol control and adapting to complex automation systems.

Main features and advantages:

Nano level positioning accuracy:

The single axis repetitive positioning accuracy reaches ± 0.5 μ m, and the dynamic tracking error is less than 1 μ m, meeting the requirements of semiconductor wafer processing.

Integrated temperature compensation module to counteract the impact of environmental temperature fluctuations on the motion trajectory.

High speed dynamic performance:

The maximum speed is 2 m/s and the acceleration is 100 m/s ², suitable for high dynamic scenarios such as laser cutting and high-speed surface mounting.

Low inertia design reduces start stop delay and response time is less than 5 ms.

Low energy consumption and high reliability:

The energy efficiency ratio reaches 90%, saving more than 25% energy compared to traditional linear motors.

IP67 protection level, suitable for clean rooms, dusty and mildly corrosive environments.

Modular compatibility:

Supports EtherCAT and CANopen communication protocols, allowing seamless integration with mainstream PLCs and motion controllers.

Provide customized installation interfaces to adapt to diverse structures such as rails and robotic arms.

Application areas:

This product is widely used in the following scenarios:

Semiconductor manufacturing: high-precision linear motion modules for wafer cutting machines and packaging equipment.

Precision machining: Nano level positioning system for laser micro carving and optical component polishing.

Automated testing: AOI optical testing equipment, high-speed scanning mechanism of X-ray flaw detector.

Medical equipment: high stability transmission components for surgical robot guide rails and pathological section analysis systems.

Technical specifications:

Parameter specifications

Model 522P35UDRL3000

Type: High rigidity linear motor

Effective travel 300 mm

Maximum thrust of 35 N

Input voltage 24-48 V DC

Working frequency DC 0-20 kHz

Positioning accuracy ± 0.5 μ m (repeatability)

Working temperature: 0 ℃ to+40 ℃

Protection level IP67

Related products:

K2G series drivers, such as K2G30-24V-BR-48, provide high-speed drive solutions compatible with 522P35UDRL3000, supporting nanometer level positioning and dynamic compensation.

Portescam rotary motor: such as the N series 12/14 model, compatible with multi axis linkage system, achieving composite motion control.

ACOMEL motion controller: such as the MC-5000 model, supports multi-channel synchronous control and expands the complex trajectory planning capability of linear motors.



DANAHER MOTION 522P35UDRL3000产品简介

产品概述：

DANAHER MOTION 522P35UDRL3000是一款高刚性直线电机，专为精密加工、半导体制造及高速自动化设备设计。该产品采用无铁芯线圈与高精度磁路设计，支持纳米级定位与高速动态响应，适用于晶圆切割、激光微加工、精密检测等对直线运动精度与稳定性要求严苛的场景。其紧凑型结构与低热变形特性使其成为高密度设备集成的理想选择，同时兼容多协议控制，适配复杂自动化系统。

主要特点和优势：

纳米级定位精度：

单轴重复定位精度达±0.5μm，动态跟踪误差小于1μm，满足半导体晶圆加工需求。

集成温度补偿模块，抵消环境温度波动对运动轨迹的影响。

高速动态性能：

最大速度达2 m/s，加速度达100 m/s²，适配激光切割、高速贴片等高动态场景。

低惯性设计减少启停延迟，响应时间小于5 ms。

低能耗与高可靠性：

能效比达90%，相比传统直线电机节能25%以上。

IP67防护等级，适应洁净室、多尘及轻度腐蚀环境。

模块化兼容性：

支持EtherCAT、CANopen通信协议，可无缝对接主流PLC与运动控制器。

提供定制化安装接口，适配导轨、机械臂等多样化结构。

应用领域：

该产品广泛应用于以下场景：

半导体制造：晶圆切割机、封装设备的高精度直线运动模块。

精密加工：激光微雕、光学元件抛光的纳米级定位系统。

自动化检测：AOI光学检测设备、X射线探伤仪的高速扫描机构。

医疗设备：手术机器人导轨、病理切片分析系统的高稳定性传输组件。

技术规格：

参数规格

型号522P35UDRL3000

类型高刚性直线电机

有效行程300 mm

最大推力35 N

输入电压24-48 V DC

工作频率DC 0-20 kHz

定位精度±0.5μm（重复性）

工作温度0℃至+40℃

防护等级IP67

相关产品：

K2G系列驱动器：如K2G30-24V-BR-48，提供与522P35UDRL3000配套的高速驱动方案，支持纳米级定位与动态补偿。

Portescap旋转电机：如N系列12/14型号，适配多轴联动系统，实现复合运动控制。

ACOMEL运动控制器：如MC-5000型号，支持多通道同步控制，扩展直线电机的复杂轨迹规划能力。
