DANAHER MOTION PA11-58B65-12E BPOX Product Introduction

Model: PA11-58B65-12E BPOX

PA11-58B65-12E BPOX is a high-precision planetary gearbox developed by Danaher Motion, specifically designed for industrial automation, medical equipment, and precision manufacturing scenarios. This product integrates Danaher Transmission’s core technologies in gear transmission, materials science, and modular design, providing high-performance and highly reliable transmission solutions.

Main features and advantages:

High transmission accuracy: Designed with spiral planetary gears, the transmission error is less than ± 0.1 °, ensuring the stability and repeatability of motion control.

Compact structure design: With a compact size (approximately 150mm x 100mm x 80mm), it is suitable for integrating devices with limited space and supports quick installation and maintenance.

Wide load adaptability: Supports continuous torque output up to 120 N · m and peak torque up to 240 N · m, suitable for heavy-duty and high dynamic load scenarios.

Low noise and temperature rise: Optimize the gear meshing and lubrication system, with operating noise below 50dB (no-load), and maintain efficient heat dissipation even in high temperature environments.

Environmental compatibility: IP65 protection level, resistant to oil pollution, dust and humidity environment, working temperature range -20 ° C to 70 ° C.

Technical specifications:

Parameter specification description

Reduction ratio 58:1 (optional customization)

Input speed 0-3000 RPM

Output torque 120 N · m (continuous)

Input shaft diameter φ 12mm (standard)

Output shaft diameter φ 25mm (standard)

Bearing type: Double row angular contact ball bearing

Weight 4.5kg (including shell)

Application areas:

Industrial automation: robotic arm joint transmission, high-speed sorting machine positioning system;

Medical equipment: CT scanner rotating platform, surgical robot joint drive;

Semiconductor manufacturing: high-precision transmission units for wafer handling robotic arms and packaging equipment;

Precision instruments: optical detection system stage, astronomical telescope tracking device.

Related products:

The models used in conjunction with PA11-58B65-12E BPOX in Danaher’s transmission product line include:

Danaher Motion NT series reducers: offering different reduction ratios and size configurations to meet diverse transmission needs;

SLO-SYN servo drive (such as MD808): matched drive, supports closed-loop control, and improves the overall accuracy of the system;

Kollmorgen DDR series servo motors: high-precision direct drive motors, combined with this reducer to achieve high-speed and high torque transmission.



DANAHER MOTION PA11-58B65-12E BPOX产品简介

型号：PA11-58B65-12E BPOX

PA11-58B65-12E BPOX是丹纳赫传动（Danaher Motion）研发的高精度行星减速机，专为工业自动化、医疗设备及精密制造场景设计。该产品融合了丹纳赫传动在齿轮传动、材料科学及模块化设计领域的核心技术，提供高效能与高可靠性的传动解决方案。

主要特点和优势：

高传动精度：采用螺旋齿行星齿轮设计，传动误差低于±0.1°，确保运动控制的稳定性与重复定位精度。

紧凑结构设计：体积小巧（约150mm×100mm×80mm），适配空间受限的设备集成需求，支持快速安装与维护。

宽负载适应性：支持连续扭矩输出达120 N·m，峰值扭矩可达240 N·m，适配重载与高动态负载场景。

低噪音与温升：优化齿轮啮合与润滑系统，运行噪音低于50dB（空载），高温环境下仍保持高效散热。

环境兼容性：防护等级IP65，耐受油污、粉尘及湿度环境，工作温度范围-20°C至70°C。

技术规格：

参数规格说明

减速比58:1（定制化可选）

输入转速0-3000 RPM

输出扭矩120 N·m（连续）

输入轴直径φ12mm（标准）

输出轴直径φ25mm（标准）

轴承类型双列角接触球轴承

重量4.5kg（含外壳）

应用领域：

工业自动化：机械臂关节传动、高速分拣机定位系统；

医疗设备：CT扫描仪旋转平台、手术机器人关节驱动；

半导体制造：晶圆搬运机械臂、封装设备的高精度传动单元；

精密仪器：光学检测系统载物台、天文望远镜跟踪装置。

相关产品：

丹纳赫传动传动产品线中，与PA11-58B65-12E BPOX协同使用的型号包括：

Danaher Motion NT系列减速机：提供不同减速比与尺寸配置，适配多样化传动需求；

SLO-SYN伺服驱动器（如MD808）：配套驱动器，支持闭环控制，提升系统整体精度；

Kollmorgen DDR系列伺服电机：高精度直接驱动电机，与该减速机组合实现高速高扭矩传动。
