DANAHER MOTION SCE906A2-002-0 1 Product Introduction

Product Overview:

SCE906A2-002-01 is a high reliability stepper motor developed by Danaher Motion, specifically designed for precision positioning and low-power scenarios. This product adopts a low inertia rotor and optimized magnetic circuit structure, supports high subdivision drive technology, and is suitable for fields such as laboratory automation equipment, medical imaging systems, and light industrial robots that require high noise and stability. It provides efficient and accurate motion control solutions.

Main features and advantages:

High precision and low vibration:

Supporting 16 subdivision driving technology, the step angle accuracy reaches ± 0.3 °, and with closed-loop feedback, it can achieve ± 0.1 ° positioning error control.

The rotor inertia is as low as 0.0015 kg · m ², and the vibration amplitude during operation is less than 5 μ m. It is suitable for precision equipment such as microscope stages and spectrometers.

Low power consumption and long lifespan:

The continuous current is only 0.5 A/phase, and the standby power consumption is less than 1 W, suitable for automation systems that operate for a long time.

Adopting a brushless design, the bearing life reaches 100000 hours, reducing maintenance frequency.

Flexible installation and scalability:

Provide NEMA 17/23 compatible interfaces and support direct embedding into standard mechanical structures.

Integrated heat sink design allows for continuous operation in a 40 ℃ environment without the need for an external fan.

Wide voltage compatibility:

The input voltage range is 12-30 V DC, suitable for different power configuration requirements.

Built in over temperature protection mechanism to prevent performance degradation caused by high temperatures.

Technical specifications:

Parameter category specification details

Model SCE906A2-002-0 1

Continuous torque 0.2 N · m (12 V DC)

Maximum speed 2000 rpm (unloaded)

Resolution 1.8 °/step (0.1125 ° after 16 subdivisions)

Input voltage 12-30 V DC

Size (mm) 42 (diameter) × 56 (axial length)

Weight 0.8 kg

Application areas:

Laboratory automation (automatic pipette, sample sorting system)

Medical equipment (endoscope positioning mechanism, drug filling machine)

Light industrial robots (collaborative robot end effectors, AGV navigation modules)

Semiconductor testing (wafer testing instrument stage, packaging equipment positioning mechanism)

Environmental monitoring (meteorological station sensor rotating platform, water quality sampling equipment)

Related products:

Kollmorgen AKM series servo motor: composed of a hybrid drive system with SCE906A2-002-01, suitable for high-precision and high-speed composite motion scenes.

Portescap brushless DC motor: provides higher power output and is suitable for load applications that require torque enhancement.

Thomson ball screw: In conjunction with this motor, it achieves high rigidity linear motion conversion and is suitable for precision robotic arm joints.

DANAHER MOTION SCE906A2-002-0 1产品简介

产品概述：

SCE906A2-002-0 1是Danaher Motion推出的高可靠性步进电机，专为精密定位与低功耗场景设计。该产品采用低惯量转子与优化的磁路结构，支持高细分驱动技术，适用于实验室自动化设备、医疗影像系统及轻型工业机器人等对静音与稳定性要求较高的领域，提供高效、精准的运动控制解决方案。

主要特点和优势：

高精度与低振动：

支持16细分驱动技术，步距角精度达±0.3°，配合闭环反馈可实现±0.1°定位误差控制。

转子惯量低至0.0015 kg·m²，运行时振动幅度小于5μm，适用于显微镜载物台、光谱仪等精密设备。

低功耗与长寿命：

连续电流仅0.5 A/相，待机功耗<1 W，适合长时间运行的自动化系统。

采用无刷设计，轴承寿命达10万小时，减少维护频率。

灵活安装与扩展性：

提供NEMA 17/23兼容接口，支持直接嵌入标准机械结构。

集成散热片设计，无需外置风扇即可在40℃环境连续工作。

宽电压兼容性：

输入电压范围12-30 V DC，适应不同电源配置需求。

内置过温保护机制，避免高温导致性能下降。

技术规格：

参数类别规格详情

型号SCE906A2-002-0 1

连续扭矩0.2 N·m（12 V DC）

最大转速2000 rpm（空载）

分辨率1.8°/步（16细分后0.1125°）

输入电压12-30 V DC

尺寸（mm）42（直径）×56（轴向长度）

重量0.8 kg

应用领域：

实验室自动化（自动移液机、样品分拣系统）

医疗设备（内窥镜定位机构、药物灌装机）

轻型工业机器人（协作机器人末端执行器、AGV导航模块）

半导体检测（晶圆检测仪载物台、封装设备定位机构）

环境监测（气象站传感器旋转平台、水质采样设备）

相关产品：

Kollmorgen AKM系列伺服电机：与SCE906A2-002-0 1组成混合驱动系统，适用于高精度与高速复合运动场景。

Portescap无刷直流电机：提供更高功率输出，适配需要扭矩增强的负载应用。

Thomson滚珠丝杠：与该电机配合，实现高刚性直线运动转换，适用于精密机械臂关节。
