DANAHER MOTION 3 S RL Product Introduction

Product Overview:

DANAHER MOTION 3 S RL is a high-precision parallel motion simulator designed specifically for industrial training, virtual reality (VR) interaction, and robot motion control research and development. This product adopts a three degree of freedom (two rotations and one movement) parallel mechanism architecture, supporting high dynamic response and sub millimeter level positioning accuracy. It is suitable for scenarios with strict requirements for space motion simulation, such as aviation simulators, medical surgical training platforms, and industrial automation testing systems. Its modular design and open interface are compatible with multiple types of sensors and control systems, allowing for flexible adaptation to complex simulation requirements.

Main features and advantages:

Dynamic motion simulation:

Support ± 180 ° rotation and ± 100 mm linear translation to achieve real-time tracking of complex trajectories in three-dimensional space.

Dynamic response time less than 50 ms, suitable for high-speed motion scenarios (such as sudden turns and emergency stops in flight simulators).

High precision control:

The positioning accuracy reaches ± 0.05 mm, with a repeatability error of less than 0.02%, meeting the requirements of precision assembly and micro operation simulation.

Integrated force feedback system, supporting tactile interaction simulation (such as resistance feedback of surgical instruments).

Low inertia and high rigidity:

Adopting a lightweight alloy structure, the system inertia is reduced by 40%, and the dynamic load response efficiency is improved.

The parallel mechanism design enhances anti-interference ability, with a vibration suppression rate of over 80%.

Compatibility and Scalability:

Supports industrial communication protocols such as EtherCAT and Profinet, compatible with mainstream PLCs and simulation software (such as MATLAB/Simulink).

Provide open API interfaces for customized development of virtual reality interaction modules.

Application areas:

This product is widely used in the following scenarios:

Industrial training: aviation pilot simulator, robotic arm operator training platform.

Medical field: simulation of surgical robot motion trajectory, minimally invasive surgical training system.

Virtual reality: dynamic interactive devices and immersive experience equipment in VR games.

Automated testing: robot joint performance testing, industrial equipment dynamic load verification.

Technical specifications:

Parameter specifications

Model 3 S RL

Type Parallel Motion Simulator

Three degrees of freedom (two rotations and one movement)

Rotation range ± 180 ° (X/Y axis)

Translation range ± 100 mm (Z-axis)

Positioning accuracy ± 0.05 mm

Dynamic response time<50 ms

Input voltage 24 V DC

Power consumption 500 W (peak)

Working temperature: 0 ℃ to+40 ℃

Protection level IP54

Related products:

Portescap linear motor: such as the N series LMS12/16, compatible with 3 S RL linear motion modules, providing high-precision power output.

K2G series drivers, such as K2G20-115V-BR-36, support multi axis synchronous control of parallel mechanisms to enhance dynamic response performance.

ACOMEL digital frequency converter: such as DVC-3000, expands the high-frequency motion control capability of simulators and adapts to high-speed simulation scenarios.
