DANAHER MOTION SV3410-00000 Product Introduction

Product Overview:

SV3410-00000 is a high-precision rotary servo motor developed by Danaher Motion, specifically designed for complex motion control scenarios. This product adopts frameless direct drive technology, combined with low inertia rotors and high-resolution encoders, with high dynamic response and low vibration characteristics. It is suitable for fields such as semiconductor manufacturing, precision testing equipment, and industrial robots that require strict accuracy and stability, helping to improve the overall efficiency and reliability of the equipment.

Main features and advantages:

High dynamic performance and low inertia design:

Continuous torque output of 4 N · m, peak torque of 8 N · m, supporting high-speed rotation (maximum speed of 3000 rpm).

The rotor inertia is as low as 0.002 kg · m ², achieving rapid acceleration and deceleration (acceleration up to 500 rad/s ²), reducing the impact of mechanical inertia on control.

Accurate positioning and low backlash:

Integrated 25 bit resolution encoder (resolution 0.1 arc sec), combined with closed-loop control algorithm, achieves positioning accuracy of ± 0.1 °.

The bearing system adopts a pre tensioning design with a radial clearance of less than 2 μ m to ensure repeat positioning stability.

Modularity and ease of integration:

No framework structure design, supports direct embedding of equipment mechanical systems, reduces transmission links.

Provide multiple interface options (such as EtherCAT, CANopen), compatible with mainstream motion control platforms.

Environmental adaptability and low maintenance:

Protection level IP67 (optional), suitable for clean rooms or mildly corrosive environments.

Brushless design, maintenance free cycle of up to 10 years, reducing full lifecycle costs.

Technical specifications:

Parameter category specification details

Model SV3410-00000

Continuous torque 4 N · m

Peak torque 8 N · m

Maximum speed of 3000 rpm

Encoder resolution 25 bits (0.1 arc sec)

Input voltage 24-48 V DC

Size (mm) 120 (diameter) × 100 (axial length)

Weight 3.2 kg

Application areas:

Semiconductor manufacturing (wafer cutting machine spindle, packaging equipment positioning module)

Industrial robots (multi joint robotic arm rotating joints, end effectors)

Precision testing (optical detector rotating platform, medical imaging equipment scanning mechanism)

Automated production line (high-speed sorting system conveyor belt drive, assembly line positioning mechanism)

New energy (photovoltaic panel rotation testing platform, lithium battery pole winding machine)

Related products:

Kollmorgen AKD servo drive: forms a closed-loop control system with SV3410-00000, supporting high-speed trajectory planning and real-time feedback.

Portescap brushless DC motor: Suitable for low-power and high-precision scenarios, it can be used in conjunction with this servo motor to achieve hybrid driving solutions.

DBL series encoder: provides higher resolution feedback signals, further improving positioning accuracy and dynamic response.

DANAHER MOTION SV3410-00000产品简介

产品概述：

SV3410-00000是Danaher Motion推出的高精度旋转伺服电机，专为复杂运动控制场景设计。该产品采用无框直接驱动技术，结合低惯量转子与高分辨率编码器，兼具高动态响应与低振动特性，适用于半导体制造、精密检测设备及工业机器人等对精度和稳定性要求严苛的领域，助力提升设备整体效率与可靠性。

主要特点和优势：

高动态性能与低惯量设计：

连续扭矩输出达4 N·m，峰值扭矩8 N·m，支持高速旋转（最高速度3000 rpm）。

转子惯量低至0.002 kg·m²，实现快速加减速（加速度达500 rad/s²），减少机械惯性对控制的影响。

精准定位与低背隙：

集成25位分辨率编码器（分辨率0.1 arc-sec），配合闭环控制算法，定位精度达±0.1°。

轴承系统采用预紧设计，径向背隙<2μm，确保重复定位稳定性。

模块化与易集成性：

无框架结构设计，支持直接嵌入设备机械系统，减少传动环节。

提供多种接口选项（如EtherCAT、CANopen），兼容主流运动控制平台。

环境适应性与低维护：

防护等级IP67（可选），适应洁净室或轻度腐蚀环境。

无刷设计，免维护周期长达10年，降低全生命周期成本。

技术规格：

参数类别规格详情

型号SV3410-00000

连续扭矩4 N·m

峰值扭矩8 N·m

最高转速3000 rpm

编码器分辨率25位（0.1 arc-sec）

输入电压24-48 V DC

尺寸（mm）120（直径）×100（轴向长度）

重量3.2 kg

应用领域：

半导体制造（晶圆切割机主轴、封装设备定位模块）

工业机器人（多关节机械臂旋转关节、末端执行器）

精密检测（光学检测仪旋转平台、医疗影像设备扫描机构）

自动化生产线（高速分拣系统传送带驱动、装配线定位机构）

新能源（光伏电池板旋转检测台、锂电池极片卷绕机）

相关产品：

Kollmorgen AKD伺服驱动器：与SV3410-00000组成闭环控制系统，支持高速轨迹规划与实时反馈。

Portescap无刷直流电机：适配低功率高精度场景，可与该伺服电机协同实现混合驱动方案。

DBL系列编码器：提供更高分辨率反馈信号，进一步提升定位精度与动态响应。
