WOODWARD 8440-2052 H Product Introduction

product overview

8440-2052 H is a high reliability power control module launched by Woodward, designed specifically for the fields of industrial automation and energy management. This module belongs to the EASYGEN-3000 series and supports parallel control of generator sets and power distribution functions. It is widely used in power, aviation, microgrids, and distributed energy systems, providing stable and efficient power management solutions.

Main features and advantages

High voltage compatibility: Supports 220V AC/DC input, suitable for MicroNet Simplex and Plus chassis, meeting the demanding power supply requirements of industrial scenarios.

Modular design: It can flexibly adapt to different chassis structures, support expansion and upgrading, and reduce system maintenance costs.

Intelligent monitoring function: Integrated LED status indicator lights (OK, input fault, power fault, over temperature fault), providing real-time feedback on the system’s health status for quick troubleshooting.

Communication protocol support: compatible with SAE-J1939, Modbus RTU and other protocols, supporting seamless integration with engine ECU and SCADA systems.

Wide temperature range operation: Suitable for environmental temperatures ranging from -25 ℃ to+80 ℃, with a protection level of IP65 (some configurations), ensuring reliability under harsh working conditions.

Energy saving optimization: adopting efficient power conversion technology to reduce energy loss and comply with green industry standards.

technical specifications

parameter description

Brand WOODWARD

Model 8440-2052 H

Input voltage 220V AC/DC

Maximum input power Simplex chassis: 1062VA; Plus chassis: 1250VA

Output frequency 6Hz (typical value)

Wiring requirements: 14AWG or 2.5mm ² wire, rated temperature 60 ℃

Communication interface CAN network Modbus RTU

Certification standards CE, UL/cUL, BDEW, ABS, Lloyds Register

Applicable chassis MicroNet Simplex/Plus

Protection level IP65 (some configurations)

application area

Power system: backup power supply for power plants, parallel control of microgrids, and distributed energy management.

Industrial equipment: aviation power units, oil and gas exploration equipment, power supply for heavy machinery.

Infrastructure: Emergency power supply guarantee for data centers, hospitals, and commercial facilities.

Special scenarios: Island energy supply, military base power system, remote area microgrid construction.

Related product recommendations

EASYGEN-3000 series controllers (such as 8440-2081, 8440-2082): support parallel connection of multiple generator sets and intelligent scheduling.

MicroNet chassis expansion module: enhances system load distribution and redundancy design.

RP-3000 Remote Panel: Implement 250 meter remote monitoring and configuration through CANopen protocol.





WOODWARD 8440-2052 H产品简介

产品概述

8440-2052 H是伍德沃德（WOODWARD）推出的高可靠性电源控制模块，专为工业自动化与能源管理领域设计。该模块属于EASYGEN-3000系列，支持发电机组并联控制与电源配电功能，广泛应用于电力、航空、微电网及分布式能源系统，提供稳定、高效的电源管理解决方案。

主要特点和优势

高电压兼容性：支持220V交流电/直流电输入，适用于MicroNet Simplex及Plus机箱，满足工业场景的严苛供电需求。

模块化设计：可灵活适配不同机箱结构，支持扩展与升级，降低系统维护成本。

智能监控功能：集成LED状态指示灯（OK、输入故障、电源故障、过温故障），实时反馈系统健康状态，便于快速排查问题。

通信协议支持：兼容SAE-J1939、Modbus RTU等协议，支持与发动机ECU、SCADA系统无缝对接。

宽温域运行：适应-25℃至+80℃环境温度，防护等级达IP65（部分配置），确保恶劣工况下的可靠性。

节能优化：采用高效电源转换技术，减少能源损耗，符合绿色工业标准。

技术规格

参数描述

品牌WOODWARD

型号8440-2052 H

输入电压220V AC/DC

最大输入功率Simplex机箱：1062VA；Plus机箱：1250VA

输出频率6Hz（典型值）

接线要求14AWG或2.5平方毫米电线，额定温度60℃

通信接口CAN网络、Modbus RTU

认证标准CE、UL/cUL、BDEW、ABS、Lloyds Register

适用机箱MicroNet Simplex/Plus

防护等级IP65（部分配置）

应用领域

电力系统：发电厂备用电源、微电网并联控制、分布式能源管理。

工业设备：航空动力装置、石油天然气勘探设备、重型机械电源供应。

基础设施：数据中心、医院、商业设施的应急电源保障。

特殊场景：海岛能源供应、军事基地电力系统、偏远地区微电网建设。

相关产品推荐

EASYGEN-3000系列控制器（如8440-2081、8440-2082）：支持多发电机组并联与智能调度。

MicroNet机箱扩展模块：增强系统负载分配与冗余设计。

RP-3000远程面板：通过CANopen协议实现250米远程监控与配置。
