SCHNEIDER LADN31 019632 is a contactor auxiliary module of the TeSys Deca series under Schneider Electric, mainly used to expand the auxiliary contact function of AC contactors. The following is a comprehensive overview of its core features and technical parameters:

1. Technical specifications

Module type: Auxiliary contact extension module, suitable for AC contactors (such as LC1 series) and contactor relays.

Contact configuration: Provides 4 auxiliary contacts (3 normally open+1 normally closed), supporting instantaneous or delayed on/off circuits.

Rated current: 10A, suitable for low voltage control circuits.

Protection level: IP2X, preventing direct contact of fingers with live parts to ensure operational safety.

Working temperature: -5 ° C to+60 ° C, suitable for wide temperature environments.

Mechanical lifespan: up to 300000 cycles, ensuring long-term stable operation.

2. Functional characteristics

Short circuit protection: Integrated overload protection function to prevent damage to equipment caused by circuit short circuits.

Easy installation: directly installed at the front of the contactor or relay, supporting quick disassembly and replacement.

Low power design: Optimize energy consumption and improve system energy efficiency.

Anti interference capability: Using EverLink terminal technology to ensure a secure connection and reduce wire stress, extending service life.

3. Compatibility and Application

Compatible devices: Suitable for Schneider LC1 series contactors (such as LC1-D09 to LC1-D620) and relays.

Application scenarios:

Industrial automation: Expansion of control circuits in industries such as mining, oil and gas, and food and beverage.

Motor control: used for motor start stop, status monitoring, and safety interlock system.

Process control: Integrated with DCS/PLC system to achieve complex logic control.

4. Additional explanation

Certification standard: Complies with industrial electrical equipment safety regulations and supports functional safety requirements.

Expansion module limitation: A maximum of 2 positive modules (including auxiliary contacts and delay modules) can be installed on the LC1-D205 to LC1-D620 contactors.

SCHNEIDER LADN31 019632是施耐德电气（Schneider Electric）旗下TeSys Deca系列的接触器辅助模块，主要用于扩展交流接触器的辅助触点功能。以下是其核心特性及技术参数的综合概述：

1.技术规格

模块类型：辅助触点扩展模块，适用于交流接触器（如LC1系列）及接触器式继电器。

触点配置：提供4个辅助触点（3常开+1常闭），支持瞬时或延时接通/分断电路。

额定电流：10A，适用于低电压控制电路。

防护等级：IP2X，防止手指直接接触带电部件，保障操作安全。

工作温度：-5°C至+60°C，适应宽温环境。

机械寿命：高达30万次循环，确保长期稳定运行。

2.功能特性

短路保护：集成过载保护功能，防止电路短路对设备造成损害。

安装便捷：直接安装于接触器或继电器前部，支持快速拆卸与更换。

低功耗设计：优化能耗，提升系统能效。

抗干扰能力：采用EverLink终端技术，确保连接牢固且减少导线应力，延长使用寿命。

3.兼容性与应用

兼容设备：适配施耐德LC1系列接触器（如LC1-D09至LC1-D620）及继电器。

应用场景：

工业自动化：采矿、石油天然气、食品饮料等行业的控制电路扩展。

电机控制：用于电动机启停、状态监测及安全联锁系统。

过程控制：与DCS/PLC系统集成，实现复杂逻辑控制。

4.附加说明

认证标准：符合工业电气设备安全规范，支持功能安全要求。

扩展模块限制：在LC1-D205至LC1-D620接触器上最多可安装2个正装模块（包括辅助触点和延时模块）。
