Product Name: XYCOM XVME-085 Proto VMEbus Non Intelligent Core Prototype VME Module

product overview

XYCOM XVME-085 is a non intelligent core prototype module based on VME bus, designed for real-time control and data processing in industrial automation, aerospace, rail transit and other fields. This module adopts the Motorola 68040 processor architecture, supports the VME64 standard, has high-performance computing capabilities and flexible I/O expansion capabilities, and is suitable for prototype development, system integration, and complex control scenarios.

Main features and advantages

Real time and reliability

Adopting real-time operating systems such as VxWorks and QNX, providing deterministic response time to ensure the stability and real-time performance of the control system.

Industrial grade component design, supporting a wide temperature working range (-20 ℃ to+70 ℃), with anti electromagnetic interference capability.

Flexible scalability

Supports multiple I/O module extensions, including serial interfaces (RS-232/422/485), parallel interfaces, Ethernet interfaces (10/100Base-T), and USB interfaces, to meet the connection needs of different devices.

Multi module collaborative work can be achieved through VME bus, adapting to complex industrial environments.

High performance hardware configuration

Processor: Motorola 68040, with a main frequency of 25 MHz, supporting complex computing tasks.

Memory and storage: 16 MB EDO DRAM (expandable up to 32 MB), 2 MB Flash storage to ensure data processing and storage requirements.

Compatibility and ease of use

Supports operating systems such as Windows CE and Linux, providing a friendly development environment and API interfaces to reduce system development difficulty.

Adopting the standard VME bus protocol, compatible with mainstream industrial control equipment, facilitating system integration and maintenance.

technical specifications

Parameter item specification description

Processor Motorola 68040, 25 MHz

Memory 16 MB EDO DRAM (maximum 32 MB expansion)

Store 2 MB Flash Memory

VME bus version VME64

Data transmission rate of 40 MB/s

I/O interface 2 x RS-232C, 1 x RS-422/485, 1 x Centronics parallel, 1 x 10/100Base-T Ethernet, USB interface

Display supports VGA interface, resolution 1280 × 1024

Working environment temperature: -20 ℃ to+70 ℃, humidity 5% to 95% (no condensation)

application area

Industrial automation: production line control, robot control, real-time monitoring of equipment.

Military and Aerospace: Flight Control Systems, Radar Systems, Data Acquisition and Processing.

Rail transit: signal control system, train operation management.

Scientific research: experimental data collection, high-precision instrument control.

产品名称：XYCOM XVME-085 Proto VMEbus非智能内核原型VME模块

产品概述

XYCOM XVME-085是一款基于VME总线的非智能内核原型模块，专为工业自动化、航空航天、轨道交通等领域的实时控制与数据处理设计。该模块采用Motorola 68040处理器架构，支持VME64标准，具备高性能计算能力和灵活的I/O扩展能力，适用于原型开发、系统集成及复杂控制场景。

主要特点和优势

实时性与可靠性

采用实时操作系统（如VxWorks、QNX），提供确定性响应时间，确保控制系统的稳定性和实时性。

工业级元器件设计，支持宽温工作范围（-20℃至+70℃），具备抗电磁干扰能力。

灵活扩展性

支持多种I/O模块扩展，包括串行接口（RS-232/422/485）、并行接口、以太网接口（10/100Base-T）及USB接口，满足不同设备连接需求。

可通过VME总线实现多模块协同工作，适配复杂工业环境。

高性能硬件配置

处理器：Motorola 68040，主频25 MHz，支持复杂计算任务。

内存与存储：16 MB EDO DRAM（最大扩展至32 MB），2 MB Flash存储，保障数据处理与存储需求。

兼容性与易用性

支持Windows CE、Linux等操作系统，提供友好的开发环境和API接口，降低系统开发难度。

采用标准VME总线协议，兼容主流工业控制设备，便于系统集成与维护。

技术规格

参数项规格描述

处理器Motorola 68040，25 MHz

内存16 MB EDO DRAM（最大32 MB扩展）

存储2 MB Flash Memory

VME总线版本VME64

数据传输速率40 MB/s

I/O接口2×RS-232C、1×RS-422/485、1×Centronics并行、1×10/100Base-T以太网、USB接口

显示支持VGA接口，分辨率1280×1024

工作环境温度：-20℃至+70℃，湿度5%至95%（无凝结）

应用领域

工业自动化：生产线控制、机器人控制、设备实时监控。

军事与航空航天：飞行控制系统、雷达系统、数据采集与处理。

轨道交通：信号控制系统、列车运行管理。

科学研究：实验数据采集、高精度仪器控制。
