Product Introduction

XYCOM 138605-098 is a high-performance industrial grade motherboard designed specifically for demanding server, data center, and industrial automation scenarios. The motherboard adopts advanced manufacturing technology and strict quality control standards, supports multi platform expansion and long-term stable operation, and is suitable for cloud computing, edge computing, industrial control and other high reliability demand fields.

Main features and advantages

High compatibility processor support: compatible with Intel Xeon Scalable series and AMD EPYC processors, providing flexible computing performance configurations.

Scalability design: equipped with 4 PCIe 4.0 slots and M.2 NVMe interface, supporting high-speed storage and AI acceleration card expansion.

Redundant power supply scheme: Dual 12V redundant power input, combined with intelligent power management module, ensures uninterrupted operation 24/7.

Industrial grade heat dissipation architecture: adopting multi fan heat dissipation and optimized design with thermal conductive silicone grease, suitable for extreme temperature environments ranging from -20 ° C to 60 ° C.

Anti interference capability: Through EMI/ESD certification, it has anti electromagnetic interference and electrostatic protection functions, suitable for high interference industrial scenarios.

technical specifications

Category parameters

The processor supports Intel Xeon Scalable (LGA 4189) and AMD EPYC (SP3)

Memory with 8 DDR4 DIMM slots, supporting up to 256GB (single 32GB)

4 SATA III storage interfaces, 2 M.2 NVMe (PCIe 4.0), 2 U.2 interfaces

Expansion slots 4 x PCIe 4.0 (x16), 1 x PCIe 3.0 (x1)

Network controller with dual Intel I210-AT Gigabit Ethernet cards, supporting redundant network configurations

Power input dual 12V redundant power supply (maximum power 500W)

Working temperature -20 ° C to 60 ° C

application area

XYCOM 138605-098 is mainly used in the following scenarios:

Cloud computing and data centers: support virtualization cluster deployment to meet high-density computing and storage requirements.

Industrial automation: compatible with PLC, robot control and other equipment, providing stable data processing capabilities.

Edge computing node: applicable to remote monitoring, IoT gateway and other scenarios requiring low latency response.

Related products

XYCOM 138605-102: High performance model in the same series, supporting more PCIe slots and higher memory capacity, suitable for AI training servers.

XYCOM 138605-085: Simplified industrial motherboard designed specifically for embedded systems, with lower power consumption and more compact size.

产品简介

XYCOM 138605-098是一款高性能工业级主板，专为严苛的服务器、数据中心及工业自动化场景设计。该主板采用先进制造工艺与严格品控标准，支持多平台扩展与长期稳定运行，适用于云计算、边缘计算、工业控制等高可靠性需求领域。

主要特点和优势

高兼容性处理器支持：兼容Intel Xeon Scalable系列及AMD EPYC处理器，提供灵活的计算性能配置。

扩展性设计：配备4个PCIe 4.0插槽与M.2 NVMe接口，支持高速存储与AI加速卡扩展。

冗余供电方案：双路12V冗余电源输入，配合智能功耗管理模块，确保7×24小时不间断运行。

工业级散热架构：采用多风扇散热与导热硅脂优化设计，适应-20°C至60°C极端温度环境。

抗干扰能力：通过EMI/ESD认证，具备抗电磁干扰与静电防护功能，适用于高干扰工业场景。

技术规格

类别参数

处理器支持Intel Xeon Scalable（LGA 4189）及AMD EPYC（SP3）

内存8个DDR4 DIMM插槽，最高支持256GB（单条32GB）

存储接口4个SATA III、2个M.2 NVMe（PCIe 4.0）、2个U.2接口

扩展插槽4×PCIe 4.0（x16）、1×PCIe 3.0（x1）

网络控制器双Intel I210-AT千兆网卡，支持冗余网络配置

电源输入双路12V冗余电源（最大功率500W）

工作温度-20°C至60°C

应用领域

XYCOM 138605-098主要应用于以下场景：

云计算与数据中心：支持虚拟化集群部署，满足高密度计算与存储需求。

工业自动化：兼容PLC、机器人控制等设备，提供稳定数据处理能力。

边缘计算节点：适用于远程监控、物联网网关等需要低延迟响应的场景。

相关产品

XYCOM 138605-102：同系列高性能型号，支持更多PCIe插槽与更高内存容量，适用于AI训练服务器。

XYCOM 138605-085：简化版工业主板，专为嵌入式系统设计，功耗更低且体积更紧凑。
