Xycom 86863BA Control Card 86864-003/B Product Introduction

product overview

Xycom 86863BA Control Card 86864-003/B is a high-performance control card designed specifically for industrial automation systems, suitable for real-time control needs of complex machinery, automated production lines, and high-precision equipment. Its core advantages lie in high stability, low latency data processing capability, and extensive hardware compatibility, which can meet the needs of industrial control in multiple scenarios.

Main features and advantages

High reliability design

Adopting industrial grade chipset and redundant power architecture, it supports stable operation in extreme temperature environments ranging from -40 ° C to 70 ° C, and its anti electromagnetic interference capability meets the IEC 61000-6-2 standard.

Flexible scalability

Supports PCIe 3.0 interface, compatible with multiple peripheral protocols such as EtherCAT and Profinet, can expand I/O channels through modular design, and supports up to 128 digital signal inputs/outputs.

intelligent fault diagnosis

Built in real-time monitoring system can automatically detect hardware abnormalities and generate logs, reducing downtime. Support remote firmware upgrade to improve maintenance efficiency.

low-power optimization

Adopting dynamic power management technology, power consumption is reduced to below 3W in idle state, suitable for energy sensitive industrial environments.

technical specifications

Parameter specifications

Product model Xycom 86863BA Control Card 86864-003/B

Interface type PCIe 3.0 x4

Working voltage 12V DC ± 10%

Maximum power consumption 15W

Storage capacity 256MB DDR4 SDRAM

Communication protocols EtherCAT, Profinet, RS-485

Working temperature -40 ° C to 70 ° C

application area

Industrial Automation

Suitable for robotic arm control, real-time data acquisition of CNC machine tools, and synchronous coordination of production lines.

energy management

Support the integration of sensor data and equipment status monitoring in wind and photovoltaic systems.

Rail Transit

Used for train signal processing, braking system control, and onboard equipment communication.

Intelligent warehousing

Integrated AGV navigation, cargo sorting system, and inventory management system.

Related products

Xycom 86864BA Expansion Board 86864-005/B: Compatible with current products, expands 16 analog signal input channels, suitable for high-precision sensor applications.

Xycom 86865CA Communication Gateway 86865-001/C： Supports industrial Ethernet protocol conversion and can collaborate with this control card to achieve cross platform data communication.

Xycom 86863BA Control Card 86864-003/B产品简介

产品概述

Xycom 86863BA Control Card 86864-003/B是一款专为工业自动化系统设计的高性能控制卡，适用于复杂机械、自动化生产线及高精度设备的实时控制需求。其核心优势在于高稳定性、低延迟数据处理能力及广泛的硬件兼容性，可满足多场景工业控制需求。

主要特点和优势

高可靠性设计

采用工业级芯片组与冗余电源架构，支持在-40°C至70°C极端温度环境下稳定运行，抗电磁干扰能力符合IEC 61000-6-2标准。

灵活扩展性

支持PCIe 3.0接口，兼容多种外设协议（如EtherCAT、Profinet），可通过模块化设计扩展I/O通道，最大支持128路数字信号输入/输出。

智能故障诊断

内置实时监控系统，可自动检测硬件异常并生成日志，减少停机时间。支持远程固件升级，提升维护效率。

低功耗优化

采用动态电源管理技术，在空闲状态下功耗降低至3W以下，适用于能源敏感型工业环境。

技术规格

参数项规格

产品型号Xycom 86863BA Control Card 86864-003/B

接口类型PCIe 3.0 x4

工作电压12V DC±10%

最大功耗15W

存储容量256MB DDR4 SDRAM

通信协议EtherCAT,Profinet,RS-485

工作温度-40°C至70°C

应用领域

工业自动化

适用于机械臂控制、CNC机床实时数据采集及生产线同步协调。

能源管理

支持风电、光伏系统中的传感器数据整合与设备状态监测。

轨道交通

用于列车信号处理、制动系统控制及车载设备通信。

智能仓储

集成AGV导航、货物分拣系统及库存管理系统。

相关产品

Xycom 86864BA Expansion Board 86864-005/B：与当前产品兼容，扩展16路模拟信号输入通道，适用于高精度传感器应用。

Xycom 86865CA Communication Gateway 86865-001/C：支持工业以太网协议转换，可与本控制卡协同实现跨平台数据通信。
