product overview

XYCOM 3100C UNMP is an industrial automation control core equipment designed for complex production environments, with high-performance data processing, flexible expansion, and stable operation capabilities. Its core functions include production line control, equipment monitoring, and data acquisition, suitable for manufacturing, food processing, pharmaceuticals, energy, and other fields, supporting multi protocol communication and modular configuration.

Main features and advantages

High performance computing and response

Equipped with a 32-bit high-performance processor (with a main frequency of 800MHz), it supports fast data processing and real-time control response, meeting the needs of high dynamic industrial scenarios.

Equipped with 256MB DDR3 RAM and 512MB Flash storage, ensuring high-capacity program and data storage capabilities.

Intuitive operation and compatibility

10.4-inch TFT color touch screen (resolution 800 × 600 pixels), providing a user-friendly interface and supporting multilingual display.

Support multiple programming languages such as ladder diagrams, structured text, and functional block diagrams to lower the development threshold.

Rich interface and communication capabilities

Provide digital/analog I/O module expansion interfaces to meet the connection requirements of industrial equipment such as sensors and actuators.

Integrated Ethernet, RS-232, RS-485 and other communication interfaces, supporting efficient data exchange between devices.

Industrial grade environmental adaptability

The working temperature range is 0 ℃ -50 ℃, and the humidity is 10% -90% (without condensation), suitable for harsh environments such as high temperature and high humidity.

Low power design (24VDC ± 10% power supply) ensures long-term stable operation.

technical specifications

Parameter item specification description

32-bit processor with a main frequency of 800MHz

256MB DDR3 RAM+512MB Flash

10.4-inch TFT color touch screen display (800 × 600)

I/O interface digital/analog module expansion interface

Communication interface Ethernet RS-232、RS-485

Programming language ladder diagram, structured text, functional block diagram

Working temperature: 0 ℃ -50 ℃

Dimensions 320mm × 240mm × 80mm

application area

Manufacturing Automation

Used for production line control, robot coordination, and real-time monitoring of equipment status.

Food and pharmaceutical industry

Support precise control of temperature, pressure and other parameters to meet the standardization requirements of production processes.

Energy and Environmental Protection System

Applied in scenarios such as power plant equipment management and sewage treatment system monitoring.

Related products

XYCOM I/O Module Series

Relationship: Provide an expansion interface module that is compatible with XYCOM 3100C UNMP to enhance signal acquisition and output capabilities.

XYCOM Communication Adapter

Relationship: Supports protocol conversion such as Ethernet and serial port, expanding the range of device interconnection.



产品概述

XYCOM 3100C UNMP是一款工业自动化控制核心设备，专为复杂生产环境设计，具备高性能数据处理、灵活扩展及稳定运行能力。其核心功能涵盖生产线控制、设备监控与数据采集，适用于制造业、食品加工、制药、能源等领域，支持多协议通信与模块化配置。

主要特点和优势

高性能计算与响应

搭载32位高性能处理器（主频800MHz），支持快速数据处理与实时控制响应，满足高动态工业场景需求。

配备256MB DDR3 RAM和512MB Flash存储，保障大容量程序与数据存储能力。

直观操作与兼容性

10.4英寸TFT彩色触摸屏（分辨率800×600像素），提供友好操作界面，支持多语言显示。

支持梯形图、结构化文本、功能块图等多种编程语言，降低开发门槛。

丰富接口与通信能力

提供数字量/模拟量I/O模块扩展接口，适配传感器、执行器等工业设备连接需求。

集成以太网、RS-232、RS-485等多种通信接口，支持设备间高效数据交换。

工业级环境适应性

工作温度范围0℃-50℃，湿度10%-90%（无凝露），适应高温、高湿等严苛环境。

低功耗设计（24VDC±10%供电），确保长期稳定运行。

技术规格

参数项规格描述

处理器32位，主频800MHz

内存256MB DDR3 RAM+512MB Flash

显示屏10.4英寸TFT彩色触摸屏（800×600）

I/O接口数字量/模拟量模块扩展接口

通信接口以太网、RS-232、RS-485

编程语言梯形图、结构化文本、功能块图

工作温度0℃-50℃

尺寸320mm×240mm×80mm

应用领域

制造业自动化

用于生产线控制、机器人协调及设备状态实时监控。

食品与制药行业

支持温度、压力等参数的精确控制，满足生产流程标准化需求。

能源与环保系统

应用于发电厂设备管理、污水处理系统监控等场景。

相关产品

XYCOM I/O模块系列

关系：提供与XYCOM 3100C UNMP配套的扩展接口模块，增强信号采集与输出能力。

XYCOM通信适配器

关系：支持以太网、串口等协议转换，扩展设备互联范围。
