product overview

XYCOM WS2786291 UNMP is an industrial grade network communication module designed specifically for real-time data transmission and protocol conversion in harsh environments. This module supports multi protocol compatibility (such as TCP/IP, Profinet, EtherCAT), integrates high-speed Ethernet interfaces and fiber optic communication functions, and is suitable for scenarios such as automation systems, rail transit, energy monitoring, etc. that require extremely high network stability.

Main features and advantages

High bandwidth and low latency

Supports 10/100/1000Mbps Ethernet interfaces, combined with hardware acceleration technology, to achieve data transmission latency of less than 1ms, meeting real-time control requirements.

Industrial grade anti-interference design

Adopting a shielded shell and EMC protection technology, it can adapt to a wide temperature range of -40 ℃ to 70 ℃, with anti electromagnetic interference ability reaching Class B level, ensuring stable operation under harsh working conditions.

Multi protocol flexible adaptation

The built-in protocol stack supports industrial communication protocols such as Profinet, Modbus TCP, EtherCAT, etc., allowing seamless integration with PLC, SCADA systems, and third-party devices.

Redundant communication guarantee

Equipped with dual fiber optic ports (SFP interfaces), supporting redundant ring network configuration, automatically switching communication paths in case of single point failure, and improving system reliability.

Modular expansion capability

Scalable storage and encryption module through VMEbus or PCIe interface, adaptable to different security levels and storage requirements.

Technical specifications

Parameter item specification description

Communication interface 4 × 1000Mbps Ethernet (including dual fiber SFP interface)

The protocol supports TCP/IP, Profinet, EtherCAT, Modbus TCP

Power input 24VDC, redundant power supply (supports dual power supply)

Physical dimensions VMEbus single height/double width standard size

Working temperature range -40 ℃ to 70 ℃

Seismic/Impact Resistance IEC 61373 Standard (Railway Applications)

application area

Industrial automation system

As the core communication node of distributed control network, it connects PLC, sensors and actuators to achieve millisecond level real-time data exchange.

Rail Transit Control

Support data synchronization between onboard and ground equipment to meet high reliability communication requirements, such as signal control and passenger information systems.

Energy and power monitoring

Used for substation automation systems to achieve remote equipment status monitoring and fault diagnosis.

Intelligent warehousing and logistics

Integrate AGV (Automated Guided Vehicle) and warehouse management system, optimize path planning and resource scheduling through high-speed network.

Related products

XYCOM VME-524

XYCOM SFP-10G

XYCOM PCIe-322



产品概述

XYCOM WS2786291 UNMP是一款工业级网络通信模块，专为严苛环境下的实时数据传输与协议转换设计。该模块支持多协议兼容性（如TCP/IP、Profinet、EtherCAT），集成高速以太网接口与光纤通信功能，适用于自动化系统、轨道交通、能源监控等对网络稳定性要求极高的场景。

主要特点和优势

高带宽与低延迟

支持10/100/1000Mbps以太网接口，结合硬件加速技术，实现数据传输延迟低于1ms，满足实时控制需求。

工业级抗干扰设计

采用屏蔽外壳与EMC防护技术，适应-40℃至70℃宽温环境，抗电磁干扰能力达Class B等级，确保恶劣工况下的稳定运行。

多协议灵活适配

内置协议栈支持Profinet、Modbus TCP、EtherCAT等工业通信协议，可无缝对接PLC、SCADA系统及第三方设备。

冗余通信保障

配备双光纤端口（SFP接口），支持环网冗余配置，单点故障时自动切换通信路径，提升系统可靠性。

模块化扩展能力

通过VMEbus或PCIe接口可扩展存储、加密模块，适配不同安全等级与存储需求。

技术规格（示例）

参数项规格描述

通信接口4×1000Mbps以太网（含双光纤SFP接口）

协议支持TCP/IP、Profinet、EtherCAT、Modbus TCP

电源输入24VDC，冗余电源（支持双路供电）

物理尺寸VMEbus单高/双宽标准尺寸

工作温度范围-40℃至70℃

抗震/抗冲击能力IEC 61373标准（铁路应用）

应用领域

工业自动化系统

作为分布式控制网络的核心通信节点，连接PLC、传感器与执行机构，实现毫秒级实时数据交互。

轨道交通控制

支持车载与地面设备间的数据同步，满足高可靠性通信需求，例如信号控制、乘客信息系统。

能源电力监控

用于变电站自动化系统，实现远程设备状态监测与故障诊断。

智能仓储物流

集成AGV（自动导引车）与仓储管理系统，通过高速网络优化路径规划与资源调度。

相关产品

XYCOM VME-524

高性能VMEbus处理器模块，配备Intel Core i5 CPU，可与XYCOM WS2786291 UNMP协同运行，承担复杂计算与网络管理任务。

XYCOM SFP-10G

千兆光纤收发器模块，专为XYCOM WS2786291 UNMP的SFP接口设计，支持长距离（30km）光纤通信。

XYCOM PCIe-322

PCIe扩展卡，提供额外存储接口（如SATA III），可扩展XYCOM WS2786291 UNMP的本地数据存储能力。
