Product Name:VMIVME2540

Product Type:Intelligent Counter/Controller Module

product overview

VMIVME2540 is a high-performance VME bus intelligent counter/controller module developed by General Electric(GE),specifically designed for industrial automation systems.This module supports multi-channel digital signal measurement and generation functions,integrates 24 discrete input/output interfaces,and is equipped with an onboard 15 MHz 68HC000 microprocessor,which can independently perform complex control tasks.Its design follows the IEEE 754 floating-point standard and is suitable for high-precision counting,frequency measurement,pulse sequence generation,and motion control scenarios.

Main features and advantages

High precision counting and measurement capability

Event count up to 4 Gigabit events,supports continuous measurement mode,and can repeat tasks without the need for host involvement.

The frequency measurement range is wide(1.16×10⁻³Hz to 2.5 MHz),and the cycle/pulse width measurement range covers 400 ns to 8.5899×10⁶seconds(32-bit floating point mode).

Flexible channel configuration

Provide 4/8/16/24 channel optional configurations,support differential and single ended signal input,compatible with RS-422 differential interface and single ended TTL input.

24 discrete output channels are programmable,supporting a voltage range of±10 V,with each channel absorbing/outputting a current of up to 10 mA,suitable for driving industrial loads.

Real time control and compatibility

The onboard 15 MHz 68HC000 CPU simplifies configuration through a command driven interface,and users can directly operate measurement,timing,and output functions through the memory mapping interface.

Compliant with VMEbus interface standards(A32/A24/D32/D16/D8),supports 64 KB VME bus memory windows,and is compatible with industrial control system ecosystems.

Motion and Position Control

Support orthogonal position measurement(sin/cos signal,1 MHz frequency),provide±1/4 wave control resolution,with a maximum step rate of 1.25 MHz.

technical specifications

Parameter item specification value

Event counting capability of 4 Gigabit events

Frequency measurement range 1.16×10⁻³Hz to 2.5 MHz

Number of output channels:24 channels(optional 4/8/16/24)

Processor model 15 MHz 68HC000 microprocessor

Interface type RS-422 differential,single ended TTL

VME bus interface A32/A24/D32/D16/D8(slave interface)

Memory window 64 KB VMEbus memory

IEEE 754-1985 Data Exchange Standard(32-bit Floating Point Operations)

application area

Industrial Automation

Used for counting production line equipment,sensor signal processing,and robot motion control,such as automotive testing,elevator control,bridge crane positioning,etc.

Precision Instruments and Laboratories

Support measurement of rotational axis velocity/acceleration,medical equipment positioning,and astronomical telescope tracking system.

Electricity and Energy

Integrated into the gas turbine control system,achieving high-precision timing management and status monitoring.
