ABB 60.13.9.024.0040 is a relay locator module in the ABB medium voltage AC frequency converter ACS6000 series,mainly used for relay status detection,fault location,and signal transmission.The following is a comprehensive introduction to its core functions and technical features:

1、Core functions

Relay status monitoring

Real time detection of the on/off status of relay contacts,supporting identification and feedback of input signals for dry contacts or relay contacts.

Compatible with multiple relay types(such as safety relay BN5930.48,auxiliary relay DILA-22,etc.),suitable for the diverse needs of frequency converter control systems.

Fault diagnosis and localization

Through the built-in logic analysis function,quickly locate issues such as open circuits,short circuits,or poor contacts in relay circuits.

Provide fault codes or signal indications to assist maintenance personnel in accurately troubleshooting problems and reducing downtime.

Signal transmission and expansion

Support the transmission of digital signals to the main control unit of the frequency converter or external control systems(such as the CDU312R control panel)to achieve status monitoring and interlocking control.

Compatible with screw terminals(SK8_14_20,SK14,etc.)and shielded connection terminals to ensure stability and anti-interference of signal transmission.

2、Technical parameters

Parameter specifications

Input voltage 24V DC(compatible with safety relay BN5930.48,etc.)

Number of channels:Single module supports independent detection of multiple channels(specific number of channels needs to refer to system configuration)

Protection level IP65(suitable for dust and moisture in industrial environments)

The communication interface supports integration with ABB frequency converter protocols(such as MODBUS)or standard industrial buses(Profibus)

Working temperature-20°C to+55°C

3、Application scenarios

Variable frequency drive control system

Used for auxiliary relay status monitoring of ACS6000 frequency converter,ensuring the normal execution of motor start stop and protection logic.

Industrial safety interlock

Integrated into the Emergency Shutdown(ESD)system,detecting the status of safety relay contacts,triggering fault alarms or shutdown protection.

Equipment maintenance

Quickly locate relay circuit faults,improve maintenance efficiency,suitable for key equipment control in industries such as power,metallurgy,and chemical engineering.

4、Technical advantages

high reliability

Adopting industrial grade anti-interference design to adapt to harsh environments such as vibration and electromagnetic noise.

Modular compatibility

Support collaboration with other modules of ABB frequency converters,such as electronic time relay CT-APS.22 and miniature circuit breaker FAZ-C6/1,for flexible expansion.

Intelligent diagnosis

Reduce the complexity of manual troubleshooting and improve system availability through status feedback and fault codes.
