Description:

The 802T-HPE​ is a metal plug-in oiltight limit switch manufactured by Allen-Bradley (Rockwell Automation) as part of the Bulletin 802T family — a heavy-duty electromechanical position-sensing switch built for machine tools, conveyors, transfer machines and process equipment where a simple proximity sensor will not survive the environment. It is catalogued as a complete switch (head and body) with lever-type, spring-return, high-operating-torque actuation, two snap-acting circuits, and clockwise plus counterclockwise operation.The defining characteristic of the 802T-HPE​ is the plug-in architecture. The switch consists of a permanently wired base and a plug-in head-and-body cartridge, so a worn or damaged switch can be replaced by unplugging the cartridge and plugging in a new one — the field wiring in the conduit hub is never disturbed. Housed in a die-cast metal body sealed to NEMA 4, 13 and 6P (IP67) with an oiltight gasket, carrying A600-rated contacts at 10 A thermal, and specified for extended low-temperature service down to -40 °C, the 802T-HPE​ is the switch that gets specified when the alternative is a sensor that will be destroyed by coolant, chips, washdown or cold.Note on the suffix: 802T-HPE​ is the base catalogue number, and Rockwell appends suffixes for connection and option variants — “J1” selects a 5-pin mini-type quick-disconnect receptacle (giving 802T-HPEJ1), “Y” selects factory-fitted pre-wired STOOW cable, and “S6” selects M20 metric conduit entry. The operating lever is selected separately, which is a detail that catches many first-time buyers.

Application Scenarios:

A machine-tool builder makes automatic turret lathes that run three shifts flood-cooled with straight cutting oil, and every axis needs a hard end-of-travel limit and a home reference. For years the builder used a general-purpose micro switch in a sheet-metal guard, and the failure pattern was always the same: oil wicks past the seal, chips pack around the actuator, and the switch either sticks closed — which is genuinely dangerous on a limit function — or fails open and stops the machine. Each failure meant a maintenance technician unlocking the enclosure, disconnecting the conduit, pulling the wires, and re-terminating a new switch, typically forty minutes of downtime on a machine that bills out by the hour.Swapping to the 802T-HPE​ changes that picture on three fronts. First, the NEMA 4/13 oiltight, IP67-sealed die-cast body simply resists the coolant and chip ingress that killed the previous switch. Second, the plug-in construction changes the repair: the base stays bolted to the machine with its conduit and wiring untouched, and the technician unplugs the cartridge and plugs in a replacement. What used to be forty minutes of re-termination becomes a couple of minutes, and importantly, the possibility of a wiring error during a hurried repair disappears. Third, the high operating torque and the snap-acting contact block give a decisive, repeatable switch point at 9° of lever travel, so the home-position reference does not drift as the mechanism wears — which is the difference between a machine that holds tolerance and one that slowly loses it.That combination is why the 802T-HPE​ and its Bulletin 802T siblings turn up across heavy industry. On conveyor systems they confirm that a diverter or stop blade has reached position. On transfer machines and indexing tables they verify clamp and locate sequences. On milling and boring machines and radial drills they provide axis limits and interlocks. In cold-storage warehouses, outdoor bulk-handling plant and unheated process buildings, the extended low-temperature rating is the deciding factor, because a standard switch with a conventional seal stiffens and leaks well before the machine itself stops working. In every case, the 802T-HPE​ addresses one pain point: position feedback that must keep working where oil, chips, water, impact and cold are permanent conditions rather than occasional events.

Parameter:
