Application Scenarios:
A 33 kV substation has a bus-section breaker with an automatic transfer scheme. The legacy timing relay in the synchronising circuit verifies that both sides are energised and waits a set delay — but it has no true phase-angle supervision. Under normal conditions the scheme behaves itself. Under stress — a standby generator starting onto a dead bus section, an auto-reclose after a fault, an operator-initiated transfer during a disturbance — it closes on a phase angle it should never have accepted. The result is a current surge into the machine, a mechanical shock to the windings and the shaft, and a breaker that has just absorbed a closing duty it was never rated for. Nothing trips immediately. The damage accumulates silently, and it is discovered years later as insulation failure or a cracked coupling.This is exactly the failure 424K1105 is engineered to prevent. Because 424K1105 measures the actual vector difference between the two sources — magnitude, frequency and phase angle, continuously and simultaneously — rather than inferring synchronism from elapsed time, it refuses to release the close circuit unless the sources are genuinely within the window the protection study defined. Where the scheme also needs to energise a dead bus or a dead line, the Type 25V function switch provides that permissive deliberately and visibly, rather than leaving it to an operator’s judgement in an emergency. The pain point it addresses is the most expensive kind of electrical failure: the one that does not announce itself at the moment it happens.
Parameter:
| Main Parameters | Value/Description |
|---|---|
| Product Model | 424K1105 (Circuit Shield™ catalog series 424K — test case) |
| Manufacturer | ABB (Asea Brown Boveri), Power Automation and Protection Division, Allentown PA — Swedish / US origin per build |
| Product Category | Synchronism check relay, ANSI device 25 — Type 25V (sync check with dead-bus / dead-line options) |
| Input Voltage | 120 V AC nominal, 50/60 Hz; 140 V AC maximum continuous; at least 90 V must be present at either line or bus input to energise the relay. Both inputs must be taken from the same phase and must be sinusoidal |
| Burden | 2 VA at 1.0 power factor — self-powered from the PT inputs, so no separate control power supply is required |
| Output Contacts | 2 Form C contacts. Per contact at 125 V DC: 30 A closing, 5 A continuous, 1 A opening (resistive), 0.3 A opening (inductive) |
| Vector Difference Setting | Magnitude of vector difference voltage, continuously adjustable 0 to 80 V. This single setting defines the closing characteristic in terms of magnitude, frequency and phase combined |
| Time Delay | Pickup adjustable — nameplate ratings of 1 s (range 0.1–1.5 s) or 10 s (range 1–15 s). Actual delay equals dial setting × nameplate rating. Dropout: 1 cycle |
| Dead-Bus / Dead-Line | Type 25V only: adjustable 0 to 120 V, factory set at 30 V. Front-panel function switch selects sync check only, high bus–dead line, high line–dead bus, or both |
| Operating Temperature | −20 °C to +70 °C |
| Seismic Capability | Greater than 6 g ZPA, either axis, biaxial multi-frequency vibration without damage or malfunction (ANSI/IEEE C37.98) |
| Transient Immunity | Greater than 2500 V, 1 MHz bursts at 400 Hz repetition rate, continuous — ANSI C37.90.1 SWC, fast transient and EMI tested |
| Dielectric Strength | 2000 V AC RMS for 60 seconds, all circuits to ground |
| Construction & Mounting | Drawout case for conventional semi-flush panel mounting; all connections at numbered rear terminals; settings on the front panel behind a removable clear cover; front-panel metal plate must be wired to the case terminal marked “G” |
| Special Features | Integral test facilities (the 424 series adds built-in test over the 224 series); built-in test function operable with both sources energised and in synchronism; continuously rated inputs; target/operation indicator; 2-year warranty; UL recognized |
