Description

GE HYDRAN M2​is a third-generation transformer gas monitoring system manufactured by General Electric(GE),designed for continuous dissolved gas analysis(DGA)in power transformers.This compact,permanently installed online monitoring device continuously measures fault gases and moisture dissolved in transformer oil,providing real-time data to detect potential problems early and prevent transformer failures.

Application Scenarios

In a major utility company’s substation network,GE HYDRAN M2​systems were deployed to monitor critical 230kV transformers that had experienced multiple unplanned outages due to insulation degradation.The existing monitoring system relied on periodic manual oil sampling and laboratory analysis,which provided delayed results and failed to detect developing faults in time.This approach resulted in two catastrophic transformer failures within 18 months,causing extended power outages affecting over 50,000 customers and repair costs exceeding$2 million per incident.

The modernization project involved installing HYDRAN M2​units on 24 critical transformers across the transmission network.The devices were configured with composite gas sensors to continuously monitor hydrogen,carbon monoxide,ethylene,and moisture levels.The system’s built-in mathematical model based on IEEE standards provided real-time transformer health assessments,including estimated winding hot spot temperatures and insulation aging rates.The implementation achieved 99.8%system availability,reducing unplanned outages by 90%and detecting developing faults 8-12 months before traditional lab tests.The early warning capabilities prevented three potential transformer failures,saving an estimated$6 million in replacement costs and avoiding 72 hours of customer outage time.

Parameter

Main Parameters

Value/Description

Product Model​

HYDRAN M2​

Manufacturer​

General Electric(GE)

Product Category​

Transformer Gas Monitoring System

Detected Gases​

H₂(0-2000ppm),CO(0-5000ppm),C₂H₄(0-1000ppm)

Moisture Measurement​

0-100%relative humidity

Measurement Principle​

Thermal Conductivity Detection(TCD)

Accuracy​

±1%FS or±2ppm

Response Time​

<30 minutes(90%step change)

Operating Temperature​

-25°C to+65°C

Power Supply​

100-240VAC,50/60Hz or 24V DC

Communication Protocols​

IEC 60870-5-104,Modbus TCP,DNP3

Enclosure Rating​

NEMA 4X(IP66)

Dimensions​

482×132×400mm(19″rack)

Weight​

15.8kg

Sensor Life​

5 years(field replaceable)

Data Storage​

16GB internal memory

Certifications​

IEEE C57.104 Class III,IEC 60567

Technical Principles and Innovative Values

Innovation Point 1:Advanced Thermal Conductivity Detection Technology

GE HYDRAN M2​employs GE’s proprietary Thermal Conductivity Detector(TCD)array with dual-channel configuration,achieving 98%measurement accuracy across the operating temperature range.The system uses gas-permeable membranes and combustible gas detectors to continuously monitor dissolved gases in transformer oil,with 0.5ppm resolution for hydrogen,carbon monoxide,and ethylene.The dual-channel TCD configuration eliminates methane interference through differential measurement,providing more accurate fault gas analysis compared to single-sensor systems.This technology enables early detection of thermal faults and partial discharge activities with response times under 30 minutes for 90%step changes.

Innovation Point 2:Built-In Transformer Mathematical Model

The device incorporates a transformer mathematical model based on IEEE and IEC standards,converting raw gas concentration data into actionable real-time information.This model calculates critical parameters including estimated winding hot spot temperature,humidity in paper insulation,moisture bubbling temperature,insulation aging rate,overload capacity,and cooling efficiency.By providing these advanced diagnostics,HYDRAN M2​moves beyond simple gas monitoring to comprehensive transformer health assessment,enabling predictive maintenance strategies and extending transformer service life.

Innovation Point 3:Multi-Gas Diagnostic Capabilities

HYDRAN M2​uniquely correlates the H₂/CO ratio to identify cellulose decomposition while monitoring C₂H₄for oil overheating detection.This multi-gas diagnostic approach provides early warning of different fault types:hydrogen indicates partial discharge,carbon monoxide signals paper insulation degradation,and ethylene indicates oil overheating.The system’s automatic baseline correction and drift compensation maintain±1%FS accuracy over the 10-year operational lifespan,with automatic zero-point adjustment compensating for seasonal temperature variations.

Innovation Point 4:Enhanced Cybersecurity and Communication

The system features secure boot firmware and role-based access control that meet NERC CIP-005 requirements for critical infrastructure protection.The isolated RS-485 port enables safe connection to legacy RTUs without network exposure,while supporting multiple communication protocols including IEC 60870-5-104,Modbus TCP,and DNP3.The front-mounted LCD displays real-time gas trends with 15-minute interval logging to 16GB internal memory,and the system can be integrated with GE’s Perception™transformer fleet management software for centralized monitoring.

Application Cases and Industry Value

Case Study:Transmission Substation Modernization

A regional transmission operator in North America implemented GE HYDRAN M2​systems across 36 critical 230kV and 500kV transformers that were approaching the end of their design life.The existing monitoring approach relied on annual oil sampling and laboratory analysis,which provided delayed results and limited visibility into developing faults.The utility had experienced two major transformer failures in the previous five years,resulting in extended outages and replacement costs exceeding$4 million per incident.

The project deployed HYDRAN M2​units with composite gas sensors and integrated temperature and load monitoring capabilities.The systems were configured to provide real-time alerts for hydrogen levels exceeding 100ppm,carbon monoxide above 500ppm,and moisture content over 20%relative humidity.The implementation detected developing thermal faults in three transformers 8-12 months before they would have been identified through traditional lab testing.Early intervention allowed for scheduled maintenance during planned outages,avoiding unplanned downtime and extending transformer life by an estimated 5-7 years.The project achieved a return on investment within 18 months through avoided replacement costs and reduced outage time.

Case Study:Industrial Plant Power Reliability Improvement

A large steel mill with critical arc furnace transformers implemented GE HYDRAN M2​monitoring to prevent production interruptions caused by transformer failures.The plant had experienced multiple unplanned outages due to transformer insulation degradation,resulting in production losses exceeding$500,000 per incident and significant equipment damage.

The installation included HYDRAN M2​units on four 60MVA arc furnace transformers,configured with hydrogen-only sensors for faster response times and lower maintenance requirements.The systems were integrated with the plant’s SCADA system through Modbus TCP communication,providing real-time monitoring to the central control room.The implementation detected developing partial discharge activity in one transformer six months before failure,allowing for scheduled replacement during a planned maintenance shutdown.The early warning system prevented an estimated$2 million in production losses and equipment damage,while reducing maintenance costs by 40%through optimized maintenance scheduling.

Related Product Combination Solutions

HYDRAN 201Ti:Advanced 8-gas analyzer with C₂H₂detection capability for comprehensive transformer gas analysis,complementing HYDRAN M2’s continuous monitoring with detailed diagnostic capabilities.

IS220UCSAH1A PAMC Acoustic Monitor:Processor module for acoustic partial discharge monitoring,providing complementary fault detection capabilities when integrated with HYDRAN M2​gas monitoring systems.

IC697CPX928 CPU Module:GE Fanuc 90-70 PLC CPU module for industrial control systems that can interface with HYDRAN M2​for integrated transformer protection and control.

SR745-W2-P1-G1-HI-E-H Motor Protection Relay:Motor protection relay that can be coordinated with HYDRAN M2​monitoring for comprehensive equipment protection in industrial applications.

IS215UCVEM08B Printed Circuit Board:Control board for GE Mark VI turbine control systems that can integrate with HYDRAN M2​for generator transformer monitoring in power generation applications.

Perception™Transformer Fleet Management Software:GE’s digital platform for centralized monitoring and analysis of multiple HYDRAN M2​devices across a transformer fleet,enabling predictive maintenance and asset management.
